Crossover w no lift?

Discussion in '1973-1991 K5 Blazer | Truck | Suburban' started by G.M.H, Sep 19, 2006.

  1. G.M.H

    G.M.H Registered Member

    Joined:
    Oct 6, 2002
    Posts:
    78
    Likes Received:
    0
    Location:
    wpg. mb canada
    Is anyone running a crossover with little or no lift? I have 2 1/2" skyjacker springs and I am wondering what pitman arm I would need etc. to clear the springs,or if there are any problems at all with clearance?

  2. Muddytazz

    Muddytazz 1 ton status

    Joined:
    Jun 30, 2002
    Posts:
    20,073
    Likes Received:
    0
    Location:
    Salem, Or.
    IIRC, crossover steering was designed for 4" and up lifts.

  3. southernspeed

    southernspeed 1/2 ton status GMOTM Winner

    Joined:
    Dec 24, 2003
    Posts:
    4,395
    Likes Received:
    50
    Location:
    VA
    Do a search. I can't remember who, may have been a Mod actually, covered this in depth a few months ago. Lots of opinions and the outcome. Check it out.

  4. wayne

    wayne 3/4 ton status

    Joined:
    Feb 1, 2001
    Posts:
    6,178
    Likes Received:
    0
    Location:
    Carlisle, Pa
    I have 3" front springs and crossover with no problems. Make sure your draglink is designed for the amount of lift you have.

  5. 79k20350

    79k20350 3/4 ton status

    Joined:
    Nov 22, 2004
    Posts:
    7,757
    Likes Received:
    1
    Location:
    Ct
    I believe it was mrk5 who did it

  6. MTBLAZER89

    MTBLAZER89 3/4 ton status Premium Member GMOTM Winner

    Joined:
    Aug 14, 2001
    Posts:
    7,272
    Likes Received:
    236
    Location:
    Oak Harbor, WA
    It was mudhog. I believe he ran 2.5 inch springs and x-over before he moved up to 4" springs. It can be done, but you will need bumpstops for sure to prevent spring pitman arm issues on uptravel.

  7. stallion85

    stallion85 1/2 ton status

    Joined:
    Jul 11, 2003
    Posts:
    3,659
    Likes Received:
    0
    Location:
    Cedar City, UT
    I ran x over for a few years with only 2.5" lift. I ran ORD bent draglink and still had contact with the engine crossmember sometimes. It never was a problem but it scarred up the metal. You can get a High Clearance crossmember or cut your existing one down a bit to clear. I had the factory bumpstops and the Ford pitman arm too!

  8. stallion85

    stallion85 1/2 ton status

    Joined:
    Jul 11, 2003
    Posts:
    3,659
    Likes Received:
    0
    Location:
    Cedar City, UT
    What the **** is wrong with the forum lately? Everytime I post I have some sort of problems! Sorry about the multiple post, but it won't let me delete them now:mad:

  9. G.M.H

    G.M.H Registered Member

    Joined:
    Oct 6, 2002
    Posts:
    78
    Likes Received:
    0
    Location:
    wpg. mb canada
    Thanks for the input. I would definitely have to get rid of the original x-member. I have moved the engine 4" back in the frame (since I don't have the blazer body) so I would probably have to fab a custom one.

    [​IMG]
