driveline angle finder.. pics inside..

Discussion in 'The Garage' started by 78Suburban, Jul 12, 2006.

  1. 78Suburban

    78Suburban 1/2 ton status

    Joined:
    Jul 4, 2005
    Posts:
    2,609
    Likes Received:
    0
    Location:
    Georgia
    [​IMG]

    will this work ok for finding my rear driveshaft angle? Any advise on how exactly to use it?
    thanks,
    James

  2. sandawgk5

    sandawgk5 3/4 ton status

    Joined:
    Oct 28, 2003
    Posts:
    6,881
    Likes Received:
    1
    Location:
    Kitsap County PACNORWEST
    Mine looks just like that but it is black not blue.

    Ira

  3. goldwing2000

    goldwing2000 Guest

    Should work fine.

    Measure the driveshaft angle and record it.
    Measure the pinion angle and record it.
    Measure the t-case yoke angle and record it.

    Subtract t-case yoke angle from driveshaft angle to get your front u-joint angle.
    Repeat for pinion to get rear u-joint angle.

    Optimally, they should be within a couple degrees of each other on a street-driven vehicle.

  4. 78Suburban

    78Suburban 1/2 ton status

    Joined:
    Jul 4, 2005
    Posts:
    2,609
    Likes Received:
    0
    Location:
    Georgia
    how do I properly measure the angles, just let the magnet stick on the side so that its flush with the way the pinion, or driveshaft is pointing?

  5. goldwing2000

    goldwing2000 Guest

    No, you hang it off the bottom of each piece. The pointer is weighted and will swing to the bottom, then you read the number which will give you degrees off of either horizontal or vertical, depending on which scale you use.

    Take it out of the package and play with it. You should be able to figure it out in five minutes or less.

  6. 4xcrazy

    4xcrazy 3/4 ton status

    Joined:
    Oct 31, 2003
    Posts:
    9,472
    Likes Received:
    5
    Location:
    Olympia/Lacey, Washington
    YES, this is always the best way to learn,,,,haven't you figured this out yet???:confused: :doah: :p:

  7. 78Suburban

    78Suburban 1/2 ton status

    Joined:
    Jul 4, 2005
    Posts:
    2,609
    Likes Received:
    0
    Location:
    Georgia
    Yeah, I figured that one out a long time ago :laugh:

  8. Thunder

    Thunder 3/4 ton status

    Joined:
    Jul 20, 2000
    Posts:
    8,946
    Likes Received:
    1
    Location:
    Northeast Nevada
    That angle finder will work fine. I bought one like it only in fire engine red from Ace hardware for 10.99
    It may be a good idea for you to spend some time here:Driveline 101
    Read the whole page.Everything you need to know is pretty much covered. With pics, circles and arrows, and all that cool stuff. Itll shed some light on the subject so you dont have to play with your toy in the dark

    Last edited: Jul 12, 2006
  9. goldwing2000

    goldwing2000 Guest

    And a paragraph on the back of each one? :D

  10. drivelineman

    drivelineman 1/2 ton status

    Joined:
    Aug 23, 2000
    Posts:
    707
    Likes Received:
    0
    If you want to call me i'd be happy to give you my opinion even if you have no plans on buying- Advice is free- Jess

  11. readymix

    readymix 3/4 ton status

    Joined:
    May 30, 2004
    Posts:
    6,706
    Likes Received:
    26
    Location:
    Murrieta, California
    8x10 Color Glossy prints and a Seeing Eye Dog too:D:D

  12. goldwing2000

    goldwing2000 Guest

    I was wondrin' how many people would get that. Leave it to a swabbie. ;)

    (spoken like a true jarhead)
    [/threadjack]

    Definitely call Jesse. He's the man when it comes to all things driveline.

  13. 4X4HIGH

    4X4HIGH 1 ton status Premium Member GMOTM Winner

    Joined:
    Dec 14, 2001
    Posts:
    22,063
    Likes Received:
    71
    Location:
    Pleasanton, CA.
    Jesse is the man, i've spent a few dollars with him but before i even did i spent a bunch of time talking on the phone with him and he was happy to answer all my questions.

  14. justhorsinaround

    justhorsinaround 3/4 ton status

    Joined:
    Sep 16, 2003
    Posts:
    6,798
    Likes Received:
    0
    Location:
    Northerish Phoenix, Az
    Thanks so much. Now I have that song stuck in my head and I won't be able to get it out!!!!!:haha:

  15. Thunder

    Thunder 3/4 ton status

    Joined:
    Jul 20, 2000
    Posts:
    8,946
    Likes Received:
    1
    Location:
    Northeast Nevada
    Hmmm looks lik I "Created a Nuisance" on this thread. I just got a phonecall from officer Obie saying something about arresting me and a bunch of shamless padders.:D

  16. 78Suburban

    78Suburban 1/2 ton status

    Joined:
    Jul 4, 2005
    Posts:
    2,609
    Likes Received:
    0
    Location:
    Georgia
    measured

    I put the angle finder on the the following...

    14ff pinion angle = 15*
    driveshaft =7*
    t case output= 4*

    all of these anlges are in an upward slope, being lowest toward the back of the burb, and higher toward the front of the burb..

    I'm having a hard time understanding how all these angles relate together. I know I need to run a shim that will make my pinion point lower. Anybody know what size shim I'll need to make the angles equal?

  17. goldwing2000

    goldwing2000 Guest

    Basically, your pinion angle and t-case angle need to be within 2 degrees or so of each other, with the pinion angled slightly lower to compensate for axle wrap.

    Click that link that Thunder posted and it will tell you everything you ever wanted to know.

  18. 78Suburban

    78Suburban 1/2 ton status

    Joined:
    Jul 4, 2005
    Posts:
    2,609
    Likes Received:
    0
    Location:
    Georgia
    I'm guessing a 5* shim should do the trick.

    I'm considering a test drive to make sure I even need to shim, but that pinion angle looks pretty ugly just eyeing it..

  19. sledheadak

    sledheadak 1/2 ton status GMOTM Winner

    Joined:
    Apr 29, 2005
    Posts:
    1,283
    Likes Received:
    1
    Location:
    anchorage,alaska
    now thats a vender.:waytogo: :waytogo: wish more companys acted like that.

  20. 78Suburban

    78Suburban 1/2 ton status

    Joined:
    Jul 4, 2005
    Posts:
    2,609
    Likes Received:
    0
    Location:
    Georgia
    Jess said, assuming I measured my angles right, that I need a 7* shim. I guess I'm going to order a set of 7* steel shims, and I'm going to get a new set of center pins and u bolts, and go from there...

    I wonder if I'll be able to put on the new center pins by just taking off the old u bolts and jacking the truck up untill the springs raise up off the axle? I'll try to rig up some kinda decent jackstands :doah:
