Factory Tach were can I find one

Discussion in 'The Garage' started by Snow-Hog, Feb 18, 2007.

  1. Snow-Hog

    Snow-Hog Registered Member

    Joined:
    Jan 8, 2007
    Posts:
    14
    Likes Received:
    0
    Location:
    Cheyenne, Wy
    does anybody know were to buy or find a factory dash kit all gauges included for a 1979 pickup with the factory tach in it???????? My former Truck had one but the truck was a piece so i sold and bought a new truck and it didn't come with one. kicking myself! the new truck is awsome and that is really the only thing i wish i had off the old one. also how $$$ is it gonna cost me to get one??

  2. k2mslskier

    k2mslskier 1/2 ton status

    Joined:
    Feb 18, 2005
    Posts:
    1,524
    Likes Received:
    0
    Location:
    Tucson, AZ
    Do a search on the Phoenix and Tucson Craigslist's. I'm sure I saw one on one of those pages in the parts section recently. I'll see if I can find it. It had the whole cluster with the Tach.

    Found it.

    84 CHEVY P.U. INST. CLUSTER WITH TACH.

    Last edited: Feb 18, 2007
  3. 1BadK-30

    1BadK-30 1/2 ton status

    Joined:
    Feb 6, 2005
    Posts:
    817
    Likes Received:
    0
    Location:
    Phoenix, Arizona
    There is one on phoenix craigslists, but there also is a few on ebay.

  4. Cornfield creations

    Cornfield creations 1/2 ton status

    Joined:
    Oct 19, 2005
    Posts:
    1,283
    Likes Received:
    0
    Location:
    Jasper, Indiana
    84 gauges are different from the 79

  5. Snow-Hog

    Snow-Hog Registered Member

    Joined:
    Jan 8, 2007
    Posts:
    14
    Likes Received:
    0
    Location:
    Cheyenne, Wy
    are the 84s so much different as to they won't interchange. or is it that they will just look different??

  6. Russell

    Russell LB7 Tahoe Status Premium Member GMOTM Winner

    Joined:
    Jun 23, 2000
    Posts:
    7,923
    Likes Received:
    333
    Location:
    Fort McMurray, Alberta
    Those gauges would work fine in your truck. They were all wired the same from 78 through 87. It has a 76-79 tach and speedo already, though the gauges on the left are the new style.

    In 80, the gauges were changed from the old style blue 100 mph speedos / gas gauges to the new style yellow 85 mph speedos / gas gauges. In 83 the cruise control systems were changed from a vaccum servo style to an electronic style, which used an optical speed sensor bolted to the back of the speedometer to provide the speed signal. In 87, that optical sensor was used for the fuel injection.

  7. Chrisblazzer89

    Chrisblazzer89 1/2 ton status

    Joined:
    Oct 12, 2006
    Posts:
    1,966
    Likes Received:
    0
    Location:
    Massachusetts 02301
    Ok so what year/style trucks have the stock tach in the clusters?

  8. Russell

    Russell LB7 Tahoe Status Premium Member GMOTM Winner

    Joined:
    Jun 23, 2000
    Posts:
    7,923
    Likes Received:
    333
    Location:
    Fort McMurray, Alberta
    Usually high trim model trucks, like Sierra Classic, or Silverado. They were around from 73 through 82 - 84ish. The 73 - 75 tachs are colorless, and are fairly rare, but not worth a whole lot. The 76-79 tachs are common, and are fairly cheap, but the 80+ tachs are very rare, and go for a premium on ebay.

    I've found that K5s, burbs, and Crewcabs usually are the most likely to have a tach, in that order. The Trucks rarely got them, but if they did, it was usually in a shortbox, or a stepside.

  9. diesel4me

    diesel4me 1 ton status Premium Member

    Joined:
    Jul 24, 2003
    Posts:
    17,553
    Likes Received:
    939
    Location:
    Massachussetts
    rare here...

    I have only seen a handfull of factory tachometers ,and most all of them were in "medium duty" trucks like C-60's,school busses, or one ton dually's with manual tranny's..I think the dash cluster is the same on the C-60's,that is where I'd look first if junkyard hunting for one..:crazy:

  10. Russell

    Russell LB7 Tahoe Status Premium Member GMOTM Winner

    Joined:
    Jun 23, 2000
    Posts:
    7,923
    Likes Received:
    333
    Location:
    Fort McMurray, Alberta
    The medium duty truck tachs are also worth big bucks if you can find one... They bolt straight into a pickup, but have a vaccum gauge where the tach fuel gauge normally goes, and the tach has a fuel gauge integreated into the bottom of it.

  11. Snow-Hog

    Snow-Hog Registered Member

    Joined:
    Jan 8, 2007
    Posts:
    14
    Likes Received:
    0
    Location:
    Cheyenne, Wy
    you guys are awsome thanks for all the info i'll start lookin around.

    Ben

  12. willyrocket

    willyrocket Registered Member

    Joined:
    Mar 8, 2005
    Posts:
    24
    Likes Received:
    0
    Location:
    Cape Cod, MA.
    Isnt there something else you need to hook up a tach? I remember someone saying you need a diode or resistor when you hook up to the dizzy........

  13. Craig Artzner

    Craig Artzner 3/4 ton status GMOTM Winner

    Joined:
    Dec 16, 2006
    Posts:
    6,843
    Likes Received:
    0
    Location:
    Northeast Ohio
    I had a '78 Scottsdale K10 with the in-dash tach and TH350. It was my truck that burnt up in '97 :(

  14. nvrenuf

    nvrenuf NONE shall pass! Premium Member

    Joined:
    Jan 7, 2002
    Posts:
    13,076
    Likes Received:
    246
    Location:
    Mobile, Al.

    It's hit or miss... Most of the tach's I have seen were mid 70's trucks. No particular type of truck though as it was a stand alone option available on any truck that had gauges instead of idiot lights.

  15. Snow-Hog

    Snow-Hog Registered Member

    Joined:
    Jan 8, 2007
    Posts:
    14
    Likes Received:
    0
    Location:
    Cheyenne, Wy
    ouch that hurts when a truck burns up!! luckly i have never had that happen

  16. Craig Artzner

    Craig Artzner 3/4 ton status GMOTM Winner

    Joined:
    Dec 16, 2006
    Posts:
    6,843
    Likes Received:
    0
    Location:
    Northeast Ohio
    I found this today on eBay. It's a '75 Chevy K10 with the in-dash tach option. I'd kill to have this gauge package in my Blazer...
    [​IMG]

  17. Metrodps

    Metrodps Strange but nice guy Premium Member GMOTM Winner Author

    Joined:
    Jan 4, 2006
    Posts:
    9,726
    Likes Received:
    108
    Location:
    earth
    Yea they go for between $100 and $225.00 the highesy price I have seen on eBay.
