"Fall Guy" GMC Truck

Discussion in 'The Garage' started by grimjaw, Oct 23, 2006.

  1. grimjaw

    grimjaw 1/2 ton status

    Joined:
    Jun 19, 2004
    Posts:
    944
    Likes Received:
    0
    Location:
    Seymour, TN
    [​IMG]

    I was thinking about the old Fall Guy show due to an earlier post. I wanted a better look at the Bedside compartment. I found a sit with alot of good info and a few pics. This picture is from one of the truck that a guy in Alaska won in a contest from the show. I know questions about this truck pop up here so I thought I would post what I found.

    From the site...


    [​IMG]


    MY TRUCK!!!! - was Colts name for his GMC and was usually uttered when stolen by the bad guys, or wrecked which was just about every episode.
    The truck had a 350/V8 motor and automatic transmission with four inch lift springs. The lower front fender lips had to be cut back to clear the bigger tires which were about the largest available at the time the show aired in late '81; 15 x 36 x 16.5 Dick Cepeks on 9.75 by 16.5 inch chrome spoke rims. Standard accessories on trucks #1 and #2 were a citizens band radio, big antenna whip mounted on the bed side, chrome rollbar, 6 off road lights (Cibie's and Daylighters),a winch and a push bar with chrome brush guard. The stunt trucks had some or none of the options that #1 and #2 did (and very few had the logo). ​

    Of course Colt's truck (#1, and possibly #2 also) had a secret compartment in the bed for stashing the bad guys or storing bounty retrieval gear like a bean bag stun gun or a flywheel inside a pizza box. The bail jumpers always fell for the old pizza delivery guy trick!
    UPDATE:
    The truck pics immediately above and below were of the custom jumper built in '83 by 20th Century Fox. Mechanics Rob Johnson, Don Harback, and the rest of the shop's crew donated over 400 hours of time to build this special stunt truck to reduce the amount of scrapped trucks the show was experiencing. The 20th Century Fox accountants had veto-ed the custom jumper truck idea it seems. Built from many wrecked trucks accumulating in the back lot, it was basically a '79 and had no transfer case, front driveshaft, or front axle shafts (welded in steel rods for added strength) and was essentially a 2 wheel drive! The engine and trans were moved 3 feet back and lowered to sit half in, half below the cab (the air cleaner sat about where the center of the bench seat would be). An aluminum radiator and electric fan were centered over top of the front axle housing. A five gallon fuel cell was added and the rear driveshaft was only about 14 inches long. Burbank springs were used in both the front (7 leaf, 4 inch lift) and rear (stock height, 9 leaf, no lift, with 4 inch aluminum blocks) along with 8 KYB gas shocks, 2 per corner. Both axles were heavily trussed and gussetted with huge bump stops added. The cab floor was re-inforced along with the cab back and a roll cage through-out with down bars extending into the bed. The front windshield was Lexan and stuntman Mickey Gilbert was actually suspended by bungie cords and didn't make contact with the seat on impact. The truck was balanced before every stunt on centered jack stands, then jacks removed from the front and back (balancing was done by adding or subtracting steel plates to a weight box in the bed). Balance and lower weight were critical for a flat, smooth landing. The end result you ask? How about a truck that could survive a fall of 14 feet and jump 100 feet at 40 mph and drive back to the shop for another shoot the next day!!! After this truck was built 20th Century Fox only needed 2 others. One was a close-up truck (#1) and another was a high speed driver for camera shots (#2). At present I haven't found any info on how many seasons this truck lasted.​



  2. uberbeans

    uberbeans 1/2 ton status

    Joined:
    May 14, 2004
    Posts:
    564
    Likes Received:
    0
    Location:
    Jacksonville, Florida
    While I think that the truck is cool my favorite part of the show when I was in elementary school was this:

    [​IMG]



    [​IMG]

  3. ryoken

    ryoken Puppy Fabricator Premium Member GMOTM Winner

    Joined:
    Jun 13, 2003
    Posts:
    29,621
    Likes Received:
    1,371
    Location:
    Jersey Shore
    Never saw the secret compartment thing, cool...

  4. Cmoe

    Cmoe 1/2 ton status

    Joined:
    Feb 19, 2000
    Posts:
    2,884
    Likes Received:
    0
    Location:
    Mesa,AZ
    Amen, Brother.... I didn't miss a show and didn't miss a show of TJ Hooker with the other Heather in it eather..... I always like Locklear better....[​IMG]

  5. BROKEN-ONE

    BROKEN-ONE Registered Member

    Joined:
    Sep 15, 2005
    Posts:
    78
    Likes Received:
    0
    Location:
    kansas
    channel

    has anyone seen this on any of the tv networks latley ? i know if you have diretv the channel sleuth shows the a-team and knight rider , but i have not seen this one in a while . the truck was a childhood want .

  6. 76zimmer

    76zimmer Flyin Rat Premium Member GMOTM Winner

    Joined:
    Nov 14, 2005
    Posts:
    23,030
    Likes Received:
    1,347
    Location:
    Kzoo, Mi
    yeh this works too...[​IMG]..

  7. uberbeans

    uberbeans 1/2 ton status

    Joined:
    May 14, 2004
    Posts:
    564
    Likes Received:
    0
    Location:
    Jacksonville, Florida
    She still looks gorgeous today. I wonder what Heather Thomas is doing now?

  8. 76zimmer

    76zimmer Flyin Rat Premium Member GMOTM Winner

    Joined:
    Nov 14, 2005
    Posts:
    23,030
    Likes Received:
    1,347
    Location:
    Kzoo, Mi
    Ya think?

    [​IMG]

  9. beater_k20

    beater_k20 Banned

    Joined:
    Dec 9, 2003
    Posts:
    10,276
    Likes Received:
    0
    Location:
    Elkhart, IN
    she looks cold.

  10. yellowK20

    yellowK20 Well Lubricated Premium Member GMOTM Winner

    Joined:
    Dec 26, 2002
    Posts:
    7,601
    Likes Received:
    551
    Location:
    Wasilla AK,
    I know it's a chevy and the rims and tires different and the role bar is gone but and theres no winch but this truck looks just like it .......which is why i BOUGHT IT


    [​IMG]

    [​IMG]

  11. ARAMP1

    ARAMP1 Aviator Extraordinaire

    Joined:
    Sep 1, 2005
    Posts:
    3,983
    Likes Received:
    55
    Location:
    Memphis, TN
    I don't remember that "secret compartment" looking so ghetto.

  12. uberbeans

    uberbeans 1/2 ton status

    Joined:
    May 14, 2004
    Posts:
    564
    Likes Received:
    0
    Location:
    Jacksonville, Florida
    Lee Majors used the secret compartment to stuff Heather Thomas in when she was being "naughty".

  13. beater_k20

    beater_k20 Banned

    Joined:
    Dec 9, 2003
    Posts:
    10,276
    Likes Received:
    0
    Location:
    Elkhart, IN
    the colors are a little off. Colt's truck was two tone brown, where yours is black and silver.

    i like the black and silver better myself.
