Finally finished my Bumper (Pics)

Discussion in 'The Garage' started by Tuff84blaze, Aug 18, 2004.

  1. Tuff84blaze

    Tuff84blaze 1/2 ton status

    Joined:
    May 12, 2000
    Posts:
    119
    Likes Received:
    0
    Location:
    Liberty Lake, Washington
    Here she is, as this was the first thing I have ever attempted to build out of metal it took me about three weeks to build but at least I know it is stout /forums/images/graemlins/thumb.gif Hopefully these pics work, they are not the best quality but they will have to do for now.
    Oh yeah and thanks to all my fellow Ck5er's for inspireing me to tackle this kind of project /forums/images/graemlins/bow.gif
    [​IMG]
    [​IMG]
    [​IMG] [​IMG] [​IMG]
    [​IMG]

  2. dremu

    dremu Officious Thread Derailer Premium Member

    Joined:
    Feb 27, 2000
    Posts:
    15,970
    Likes Received:
    462
    Location:
    East of San Francisco
    /forums/images/graemlins/bow.gif

    Wow. That's stout, and clean and simple.

    I assume the shells aren't live? /forums/images/graemlins/laugh.gif

    -- A

  3. Tuff84blaze

    Tuff84blaze 1/2 ton status

    Joined:
    May 12, 2000
    Posts:
    119
    Likes Received:
    0
    Location:
    Liberty Lake, Washington
    [ QUOTE ]
    I assume the shells aren't live?

    [/ QUOTE ]
    No There not, but I thought about it though, lol. I just got tired after working on it forever without alot of tools, and was getting bored of using the grinder to cut out metal to cap off open ends. So I thought that would be fun to do, plus the say made in the U.S.A on them /forums/images/graemlins/thumb.gif

  4. blueblaze

    blueblaze 1/2 ton status

    Joined:
    Dec 4, 2001
    Posts:
    274
    Likes Received:
    0
    Location:
    Salt Lake City, UT
    Nice, I love it... /forums/images/graemlins/thumb.gif

  5. TONYP

    TONYP 1/2 ton status

    Joined:
    Aug 13, 2002
    Posts:
    2,116
    Likes Received:
    0
    Location:
    so cal
    great job, I built my own too and know how much work there is in building one of those...great job.. /forums/images/graemlins/peace.gif

  6. 84gmcjimmy

    84gmcjimmy 1 ton status

    Joined:
    Dec 3, 2003
    Posts:
    12,838
    Likes Received:
    0
    Location:
    B.C. CANADA
    woah! that looks tuff... do you have reinforments for the sides so they dont get bent in?

  7. jrsheets

    jrsheets Registered Member

    Joined:
    Mar 15, 2004
    Posts:
    68
    Likes Received:
    0
    Location:
    Katy, Texas
    id say that huge chunk of metal on the underside would do the truck /forums/images/graemlins/waytogo.gif

  8. thezentree

    thezentree 3/4 ton status

    Joined:
    Sep 19, 2003
    Posts:
    7,198
    Likes Received:
    0
    Location:
    NC
    that is a sweeeet bumper /forums/images/graemlins/thumb.gif /forums/images/graemlins/bow.gif

  9. Paxx

    Paxx 1/2 ton status

    Joined:
    Feb 9, 2003
    Posts:
    1,405
    Likes Received:
    0
    Location:
    All Over Western Canada
    damn I like that man /forums/images/graemlins/waytogo.gif Nice fab work too.

  10. Tuff84blaze

    Tuff84blaze 1/2 ton status

    Joined:
    May 12, 2000
    Posts:
    119
    Likes Received:
    0
    Location:
    Liberty Lake, Washington
    [ QUOTE ]
    woah! that looks tuff... do you have reinforments for the sides so they dont get bent in?


    [/ QUOTE ]
    Come on now do you think I would spend all that time building this and not reinforce the sides? lol. Yeah I angled back rails to reinforce it even though it probably didn't need it.

  11. 84gmcjimmy

    84gmcjimmy 1 ton status

    Joined:
    Dec 3, 2003
    Posts:
    12,838
    Likes Received:
    0
    Location:
    B.C. CANADA
    LOL, okay just asking... looks very nice!! /forums/images/graemlins/peace.gif

  12. darkshadow

    darkshadow 1 ton status

    Joined:
    Dec 6, 2003
    Posts:
    12,250
    Likes Received:
    0
    Location:
    C-eh-N-eh-D-eh
    nice looken /forums/images/graemlins/waytogo.gif

    just wondering how far back did you put the hole thin the 2 inch resever?
    its a standered hole so if it not the same you might run in to problems hooking up different resevers /forums/images/graemlins/thinking.gif

  13. fad2blk99

    fad2blk99 1/2 ton status

    Joined:
    Feb 19, 2001
    Posts:
    860
    Likes Received:
    0
    Location:
    Charleston, SC
    Nice work! /forums/images/graemlins/thumb.gif
    Good to see that the primer was expended on those shells /forums/images/graemlins/yikes.gif/forums/images/graemlins/waytogo.gif

  14. stallion85

    stallion85 1/2 ton status

    Joined:
    Jul 11, 2003
    Posts:
    3,659
    Likes Received:
    0
    Location:
    Cedar City, UT
    Wow, that looks great!! /forums/images/graemlins/peace.gif

  15. 85mudblazin

    85mudblazin 1/2 ton status

    Joined:
    Mar 26, 2004
    Posts:
    3,951
    Likes Received:
    0
    Location:
    Austin,TX
    What all is it made out of?? and how much did it all cost you if you dont mind me asking??
    Thanks
    -Chris

  16. Tuff84blaze

    Tuff84blaze 1/2 ton status

    Joined:
    May 12, 2000
    Posts:
    119
    Likes Received:
    0
    Location:
    Liberty Lake, Washington
    [ QUOTE ]
    just wondering how far back did you put the hole thin the 2 inch resever?
    its a standered hole so if it not the same you might run in to problems hooking up different resevers


    [/ QUOTE ]

    The hole is like 4.5" back. Here is a picture with a reciever, I know just about any Reese brand hitch fits it.
    [​IMG]

  17. Tuff84blaze

    Tuff84blaze 1/2 ton status

    Joined:
    May 12, 2000
    Posts:
    119
    Likes Received:
    0
    Location:
    Liberty Lake, Washington
    [ QUOTE ]
    What all is it made out of?? and how much did it all cost you if you dont mind me asking??
    Thanks
    -Chris

    [/ QUOTE ]
    -Side armor from 1" schedule 80 tubing and 2x2" square= Free from friend

    -4 Cans of paint and 3 cans of primer=$20

    -2 4.5" grinders from harbor freight= $36

    -Pipe bender from HF=$65

    -20 feet of 3x8x3/16" square tubing (enough for three bumpers)= $230

    -Lincoln welder from Home Depot with 10 spool of wire= $500

    -100+ hours spent working in the garage with cutting, grinding, welding, and classic rock blaring; and having the nosey neighbors wondering what the hell I am doing and when I am going to be done= Priceless

  18. grimjaw

    grimjaw 1/2 ton status

    Joined:
    Jun 19, 2004
    Posts:
    944
    Likes Received:
    0
    Location:
    Seymour, TN
    Very nice work. Clean, simple and strong design. Nice.

  19. 85mudblazin

    85mudblazin 1/2 ton status

    Joined:
    Mar 26, 2004
    Posts:
    3,951
    Likes Received:
    0
    Location:
    Austin,TX
    I bet that 3x8 tubing was funn to handle. /forums/images/graemlins/thumb.gif
