Front tube bumper ideas

Discussion in 'The Garage' started by stevos67k20, Mar 3, 2007.

  1. stevos67k20

    stevos67k20 1/2 ton status

    Joined:
    Sep 29, 2005
    Posts:
    140
    Likes Received:
    1
    Location:
    Somis
    hey all, i was really bored and i drew up this bumper on paint. its probably what i would try to build if i were to build one. i would also move my axle forward and add 37"tires (now i'm dreaming), any ways i'm sure alot of new builders on CK5, and I, would like to see some custom tube bumpers so lets see em! heres my junk:
    [​IMG]
    what do you think? i would love to see some more bumpers/ideas...

    if it makes any dif, its a long bed :truck: :weld: :hack: :grind:

  2. bigblazer87

    bigblazer87 1/2 ton status

    Joined:
    Dec 20, 2006
    Posts:
    333
    Likes Received:
    1
    Location:
    Elk Grove, CA
    Well, I just fidgeted with your's a little:
    [​IMG]

  3. stevos67k20

    stevos67k20 1/2 ton status

    Joined:
    Sep 29, 2005
    Posts:
    140
    Likes Received:
    1
    Location:
    Somis
    very nice, i like the skid plate, i was thinking about that too.

  4. Col_Sanders

    Col_Sanders 3/4 ton status

    Joined:
    Apr 27, 2005
    Posts:
    5,688
    Likes Received:
    1
    Location:
    KFC
    Different body style, but maybe it could help you in design.

    [​IMG]

  5. Brians89K5

    Brians89K5 1/2 ton status

    Joined:
    Jan 4, 2006
    Posts:
    535
    Likes Received:
    0
    Location:
    Rialto Ca.
    Heres a bunch of ideas, and my truck. (Mines the white one)Its what I used to brain storm my creation. Its still not finished however.




    Misc Pictures 039.jpg

    Last edited: Mar 8, 2007
  6. tRustyK5

    tRustyK5 Big meanie Staff Member Super Moderator GMOTM Winner Author

    Joined:
    Jul 23, 2000
    Posts:
    36,184
    Likes Received:
    1,388
    Location:
    E-town baby!
    Here is mine:

    [​IMG]

    [​IMG]

    Rene

  7. k5onswampers

    k5onswampers Registered Member

    Joined:
    Mar 9, 2005
    Posts:
    90
    Likes Received:
    0
    Location:
    Port Saint Lucie, Florida
    Who makes this bumper???


  8. ryoken

    ryoken Puppy Fabricator Premium Member GMOTM Winner

    Joined:
    Jun 13, 2003
    Posts:
    29,624
    Likes Received:
    1,380
    Location:
    Jersey Shore
    I've posted that 1 a dozen times... hands down my fave... compact, beefy, etc.... perfect... It's what I'll be modeling mine after...

    It's not a company.. The guy who made it hasn't chimed in the last few times I posted the pics, so I'm not sure if he's still around..

  9. GotLabs

    GotLabs 1/2 ton status GMOTM Winner

    Joined:
    Jul 30, 2005
    Posts:
    2,795
    Likes Received:
    0
    Location:
    Transient, USA
    That is Bushwhackers truck, and the photo doesn't do the bumper justice! That, by far, is the sexiest front bumper ever!!:D

  10. AZ79K5Project

    AZ79K5Project 1/2 ton status

    Joined:
    Jan 15, 2006
    Posts:
    2,082
    Likes Received:
    0
    Location:
    Arizona
    Doesn't his truck have a matching rear bumper just as sweet? I came across one last year that was VERY nice and I cannot find it again.:mad:

  11. GotLabs

    GotLabs 1/2 ton status GMOTM Winner

    Joined:
    Jul 30, 2005
    Posts:
    2,795
    Likes Received:
    0
    Location:
    Transient, USA
    [​IMG]

  12. AZ79K5Project

    AZ79K5Project 1/2 ton status

    Joined:
    Jan 15, 2006
    Posts:
    2,082
    Likes Received:
    0
    Location:
    Arizona
    That's a nice setup. The one I saw was a double tube rear, understated, but damn nice. It wrapped around the corners of the truck.

  13. k5onswampers

    k5onswampers Registered Member

    Joined:
    Mar 9, 2005
    Posts:
    90
    Likes Received:
    0
    Location:
    Port Saint Lucie, Florida
    Well now we have something to do because someone needs to tighten up and start making these bumpers becuse that bumper looks so damn good.....

  14. sebban

    sebban Registered Member

    Joined:
    Jan 18, 2005
    Posts:
    63
    Likes Received:
    0
    Location:
    sweden
    hi guys, I don't know if you saw this one before..
    it's very similar to the one you drew at the beginning of this post. (I built it myself, didn't take that long, 4 maybe 5 evenings after work.)
    Haven't mounted the winch yet though..


    [​IMG]
    [​IMG]

  15. Col_Sanders

    Col_Sanders 3/4 ton status

    Joined:
    Apr 27, 2005
    Posts:
    5,688
    Likes Received:
    1
    Location:
    KFC
    Here is my rear, it has the same swing out spare tire carrier as in Got Lab's post but I dont have pics of it now.

    [​IMG]

  16. AZ79K5Project

    AZ79K5Project 1/2 ton status

    Joined:
    Jan 15, 2006
    Posts:
    2,082
    Likes Received:
    0
    Location:
    Arizona
    Bringing this back - A have a few questions.
    Have you had any problems with this setup?
    How is the carrier secured in the closed position?
    Any more pics from different angles?

    I am in the process of building a similar bumper. I am using a spindle, wheel hub and a manual hubs off from a D44 to lock it open and assist in keeping it closed. I am having a hard time coming up with a fastener/clip/lock/clamp design to keep the carrier closed. The locking hub will not prevent rattle and will not secure the opposite side.

    I'm planning on using 1.75 x 0.120 HREW for the structure with 1/4" to the frame and the pivot mounting for the tire carrier.

    This is what I am thinking of doing:


  17. PGW

    PGW 1/2 ton status

    Joined:
    Apr 19, 2007
    Posts:
    130
    Likes Received:
    0
    Location:
    CC, TX
    How are strong are these tube bumpers to say, the stock bumper or a plate bumper?

  18. Col_Sanders

    Col_Sanders 3/4 ton status

    Joined:
    Apr 27, 2005
    Posts:
    5,688
    Likes Received:
    1
    Location:
    KFC
    Stock bumpers have NOTHING on tube bumpers. If you scratch it you can just bust out a rattle can for touch up anyway.

    I think if I could do it over again I would order the stinger style bumper instead of the swing out carrier. The swing out is a PITA in a parking lot and its also going to be a pain to get a big tire up there.

  19. BulldogK5

    BulldogK5 1/2 ton status GMOTM Winner

    Joined:
    Sep 19, 2002
    Posts:
    4,158
    Likes Received:
    0
    Location:
    Brandon, MS
    Reid Supply has many different options for the latches you are looking for. I think they are Destaco or some variant.

    How big is the spare you plan on carrying? I ask this because mine broke a few years ago and it was a swing out carrier. Although it was a different design that initially did not have a latch or anything to hold the free side down. I had to modify it after a 39.5" tire went bouncing across the road and it has not been a problem again, although it does not get driven as much as it used to.:o

    Here's a link. http://www.reidsupply.com/aDetail.aspx?N=1003805&A=TC-374&An=1003805&On=1003805&ST= Similar to what I used but there are other styles. Each style comes in many different sizes so read the specs real well. The first on I ordered was about 10" long and 3" wide.:eek1::doah:

  20. carpeonnel

    carpeonnel 1/2 ton status

    Joined:
    Jul 12, 2005
    Posts:
    1,184
    Likes Received:
    0
    Location:
    Albany, Georgia
    I'm subscribing to this thread cuz I'm wanting to tube bumpers front and rear to my K5 and y'all are right Bushwackers front bumper is awesome. Somebody definitely let us know if they can find out some more info
