lets see your exhaust!!!!

Discussion in 'The Garage' started by 01maroonz71, Feb 20, 2007.

  1. 01maroonz71

    01maroonz71 1/2 ton status

    Joined:
    Jan 8, 2007
    Posts:
    1,553
    Likes Received:
    4
    Location:
    Palmetto, fl
    how do ya'll have it, not exactly routed under the truck, but exiting...on my old z71, it was coming out the corners in the back at 45degree angles, and may do someithng like this...it seems like most 73-87's just have it dumped...not sure why, but they do.

    i wanna straight pipe it, 45degerees out the rear,

    so lets see your pics if you got em'!

  2. obijuan

    obijuan 1/2 ton status GMOTM Winner

    Joined:
    May 18, 2006
    Posts:
    4,009
    Likes Received:
    0
    Location:
    San Antonio TX
    this is the besat pic i got but it exits 45* after the rear tires. [​IMG]
    you can see it here behind the tires too. sorry for the poor pics.
    [​IMG]

  3. 01maroonz71

    01maroonz71 1/2 ton status

    Joined:
    Jan 8, 2007
    Posts:
    1,553
    Likes Received:
    4
    Location:
    Palmetto, fl
    awesome man...that's what im looking for....straight pipes, just like that.

  4. bigblazer87

    bigblazer87 1/2 ton status

    Joined:
    Dec 20, 2006
    Posts:
    333
    Likes Received:
    1
    Location:
    Elk Grove, CA
    Here, can you see it? No? Good, 'cause that's how I like it! :D
    [​IMG]
    [​IMG]

  5. AFUFO

    AFUFO 1/2 ton status

    Joined:
    Apr 26, 2006
    Posts:
    329
    Likes Received:
    0
    Location:
    Chesapeake,Virginia
    Stock manifold, no cat, rusted out turbo mufflers, and side exhaust behind the rear tires. I don't like rear exits out the back because i cant hear it as well, and when someone cuts you off on the highway you can drive up beside them with it facing their window. =D

    Hopefully going with a summit full exhaust system later in the year, 270ish bucks, full length headers, no cats, 2 super turbo mufflers, side exits in front of the rear tires.

    Might just toss on a pair of glass packs right now to replace the rusted out ones(Started up a drill and the bottom fell off).

    [​IMG]

    [​IMG]

  6. 454k30

    454k30 1/2 ton status GMOTM Winner

    Joined:
    Sep 13, 2004
    Posts:
    1,613
    Likes Received:
    0
    Location:
    California, MD
    Here is mine. It is a true dual exaust with no cross pipe. It comes out right in front of the rear tires. When I shorten the frame I am going to take those pipes over the rear axle and then straight out the back. Sorry I'm rambling my brainstorms. sorry for the darkness i took these when I saw your post.

    [​IMG]

    [​IMG]
    [​IMG]

    [​IMG]

  7. sandawgk5

    sandawgk5 3/4 ton status

    Joined:
    Oct 28, 2003
    Posts:
    6,881
    Likes Received:
    1
    Location:
    Kitsap County PACNORWEST
    Give me till next weekend and I will have my custom built 3" single done and I will post pics:D . I got the old stuff out and the first flange system in with the cat. I got the muffler and tailpipe left and hangers but I run out of light rather quickly when I get home and my shop lights are down:doah: .

    It might be done before the weekend but we will see. Either way I will post a finished product in here for you.

    Stay Tuned chil'ren:D .

    Ira

  8. Blazn83

    Blazn83 Registered Member

    Joined:
    Dec 11, 2006
    Posts:
    54
    Likes Received:
    0
    Location:
    Mechanicsville VA
    my exhaust. homeade. cheap. works. just the way I like it...

    Random Flowmaster I found in the attic..
    [​IMG]
    [​IMG]
    [​IMG]

  9. littlejimmythatcould

    littlejimmythatcould 1/2 ton status

    Joined:
    Feb 6, 2006
    Posts:
    797
    Likes Received:
    1
    Location:
    Clovis, NM
    I paid to have mine out the back at 45 degrees and my rear springs kept hitting it :doah: so I cut it off, now it exits underneath the truck. If a shackle flip is in your truck's future I would advise against gettting it out the corners. because if not done right it will be in the way. Even though it looks cool.

  10. Rednekjimmy86

    Rednekjimmy86 Registered Member

    Joined:
    Dec 6, 2006
    Posts:
    16
    Likes Received:
    0
    Location:
    Parkton, NC
    I have stock manifolds with a cat, and straight pipes with it exiting @ 45 degress. The same setup you are talking about, it does sound pretty good and I have a 305.

    Some times it can be poppy ( normally when it's not always warmed up) and I have some stainless tips on it, and the tires are always throwing dirt and crap on it when it is clean, but other then that it's pretty cool.

  11. rjfguitar

    rjfguitar 3/4 ton status GMOTM Winner

    Joined:
    Aug 28, 2002
    Posts:
    9,095
    Likes Received:
    144
    Location:
    california
  12. sandawgk5

    sandawgk5 3/4 ton status

    Joined:
    Oct 28, 2003
    Posts:
    6,881
    Likes Received:
    1
    Location:
    Kitsap County PACNORWEST
    Here is mines:D





    Ira






  13. K5Glazier

    K5Glazier 1/2 ton status

    Joined:
    May 29, 2003
    Posts:
    220
    Likes Received:
    0
    Location:
    Chandler, Az.
    Heres how I had mine done.

    DSC01405 (600 x 450).jpg

    DSC01406 (1136 x 852).jpg

    DSC01407 (600 x 450).jpg

  14. 87BrnRsd

    87BrnRsd 1/2 ton status

    Joined:
    Apr 21, 2003
    Posts:
    2,457
    Likes Received:
    0
    Location:
    Boone, North Carolina
    I would post some pics bu there is really nothing to take a pic of. Im just running open headers...nothing else.:D Oh...a good set of ear plugs too.
    -Harrison

  15. steve_kibbe

    steve_kibbe 1/2 ton status

    Joined:
    Feb 4, 2004
    Posts:
    2,895
    Likes Received:
    2
    Location:
    Spartanburg, SC
    You forgot to add that you drive your K5 to the trail:D

  16. 01maroonz71

    01maroonz71 1/2 ton status

    Joined:
    Jan 8, 2007
    Posts:
    1,553
    Likes Received:
    4
    Location:
    Palmetto, fl
    awesome guys...keep up the pics....who all is runnin straight pipes dumped???? im thinking about doing that also.

  17. muddybuddy

    muddybuddy 3/4 ton status

    Joined:
    Jan 29, 2004
    Posts:
    8,933
    Likes Received:
    1
    Location:
    Fairfax Station VA
    Ira, you got it done huh? looks sweet man!

    i love 45* out each side, mine may eventually get that

  18. rjfguitar

    rjfguitar 3/4 ton status GMOTM Winner

    Joined:
    Aug 28, 2002
    Posts:
    9,095
    Likes Received:
    144
    Location:
    california
    Strait pipes? Are you kidding? That would be really annoying and definantly illegal.

  19. Dudge

    Dudge 1/2 ton status

    Joined:
    Sep 9, 2006
    Posts:
    351
    Likes Received:
    0
    Location:
    Kentucky
    It did have 2 big blingin' chrome tips out back that werent tacked up and hit the bumper, so we cut them off and dumped em.

    [​IMG]

  20. Alex_B

    Alex_B Registered Member

    Joined:
    Feb 28, 2006
    Posts:
    33
    Likes Received:
    0
    Location:
    Newfoundland, Canada
    Dual 2 1/2", 4" Magnaflow tip's, super 40's, and race ready cut out's commin off the headers.:D

    [​IMG]
