    Thought I would start off by posting what I have been working on.

    [​IMG]

    [​IMG]

    [​IMG]

    Stripped down

    [​IMG]

    Just had to see what it was looking like

    [​IMG]

    Sectioned grill mount

    [​IMG]

    To get an idea of how much I took off each side

    [​IMG]

    Made a template for the hood

    [​IMG]

    [​IMG]

    [​IMG]

    [​IMG]

    [​IMG]

    Rough cuts on the hood

  2. mudman2882

    mudman2882 1/2 ton status

    Joined:
    Aug 3, 2002
    Posts:
    144
    Likes Received:
    0
    Location:
    Lubbock, Tx
    [​IMG]

    [​IMG]

    [​IMG]

    [​IMG]

    Hood pins done and fitting as good as I can

    [​IMG]

    [​IMG]

    [​IMG]

    New battery location

    The front is pretty much done. The rear is next.

  3. mudman2882

    mudman2882 1/2 ton status

    Joined:
    Aug 3, 2002
    Posts:
    144
    Likes Received:
    0
    Location:
    Lubbock, Tx
    Started the rear yesterday

    [​IMG]

    Cut out the wheel wells

    [​IMG]

    [​IMG]

    Whats left of the openings

    [​IMG]

    [​IMG]

    [​IMG]

    Bed sides pulled in. This is as far as I got.

    Took about 19 in off the front and 22 in from the rear.

    Enjoy :hack: :grind:

  4. tRustyK5

    tRustyK5 Big meanie Staff Member Super Moderator GMOTM Winner Author

    Joined:
    Jul 23, 2000
    Posts:
    36,173
    Likes Received:
    1,385
    Location:
    E-town baby!
    Cool deal!

    I would add some through bolts to your battery mount though, and possibly some gussets upwards. You might be surprised how much stress 80 lbs of battery can put on sheet metal...and you sure don't want the battery rolling around shorting out all over everything.

    Rene

  5. supersize75k5

    supersize75k5 OrganDonorRacing.com

    Joined:
    Feb 3, 2004
    Posts:
    8,832
    Likes Received:
    4
    Location:
    gilbert az
    sweeeeeeeeet

    i remember those days :)

    [​IMG]

  6. mudman2882

    mudman2882 1/2 ton status

    Joined:
    Aug 3, 2002
    Posts:
    144
    Likes Received:
    0
    Location:
    Lubbock, Tx
    I was thinking about that when I put it in. I have not finished it yet so I will look into that. Thanks

  7. tRustyK5

    tRustyK5 Big meanie Staff Member Super Moderator GMOTM Winner Author

    Joined:
    Jul 23, 2000
    Posts:
    36,173
    Likes Received:
    1,385
    Location:
    E-town baby!
    Busted up battery trays was why i did this:

    [​IMG]

    Definitely one of the better mods i've done.

    Rene

  8. mudman2882

    mudman2882 1/2 ton status

    Joined:
    Aug 3, 2002
    Posts:
    144
    Likes Received:
    0
    Location:
    Lubbock, Tx
    I had actually tossed around the idea of doing that exact thing. I guess I will see how it works where it is and change it if or when it breaks.

  9. SCOOBYDANNN

    SCOOBYDANNN 1/2 ton status

    Joined:
    Sep 4, 2001
    Posts:
    2,129
    Likes Received:
    21
    Location:
    El Paso, TEXAS
    Nice--you did it exactly how I helped a friends

    [​IMG]

    [​IMG]

    and mine---Mine didn't come out as cleane as your or my friends but i figure I will bash it in enough till you cant even notice.

    [​IMG]

    [​IMG]

  10. mudman2882

    mudman2882 1/2 ton status

    Joined:
    Aug 3, 2002
    Posts:
    144
    Likes Received:
    0
    Location:
    Lubbock, Tx
    [​IMG]

    do you have any pics of where the bed sides and floor meet? maybe some of the bed also?

    Did you shorten the floor or lengthen the sides at all?

  11. SCOOBYDANNN

    SCOOBYDANNN 1/2 ton status

    Joined:
    Sep 4, 2001
    Posts:
    2,129
    Likes Received:
    21
    Location:
    El Paso, TEXAS
    those are the only pics I have right now. The sides came in a little bit so we just welded sheetmetal to cover the gap. And where the bedsides met the floor we just welded up wherever the touched.

  12. CDA 455

    CDA 455 3/4 ton status

    Joined:
    Jun 2, 2006
    Posts:
    8,598
    Likes Received:
    0
    Location:
    43rd State

    Hey Rene,
    Great idea :bow: :bow: !!

    I going to use that on my rig. I'll name it "The Rene Box" after the person who gave me the idea :D !!

  13. sandawgk5

    sandawgk5 3/4 ton status

    Joined:
    Oct 28, 2003
    Posts:
    6,881
    Likes Received:
    1
    Location:
    Kitsap County PACNORWEST

    HA HA HA Rene's "BOX":haha::haha::haha:

    Ira

  14. muddermilitia

    muddermilitia ThatTrazerGuy GMOTM Winner

    Joined:
    Nov 10, 2005
    Posts:
    5,742
    Likes Received:
    76
    Location:
    NE Illinois
    Looking great, I subscribed to this so I can look at it in the future when I taper my front clip.:thumb:

  15. mudman2882

    mudman2882 1/2 ton status

    Joined:
    Aug 3, 2002
    Posts:
    144
    Likes Received:
    0
    Location:
    Lubbock, Tx
    I have some detail pics of the mounts for the front fenders and such if you ever need them. There are a bunch that I didn't post.

  16. gmc4cw

    gmc4cw 1/2 ton status GMOTM Winner

    Joined:
    Jul 19, 2006
    Posts:
    3,907
    Likes Received:
    0
    Location:
    west chester, Pa
    I would like to see how you bolted the fender to the rad support. also did you skin the fender back by the body or just bend around it. the fenders don't look like they are kinked like the others on here.

  17. blazd88

    blazd88 1/2 ton status

    Joined:
    Mar 16, 2004
    Posts:
    1,055
    Likes Received:
    0
    Location:
    Lubbock, Tx
    Looks good when the trails finish mine thats my plan.:D:D
    You going to Cruses?

  18. muddyblzr

    muddyblzr 1/2 ton status

    Joined:
    Nov 2, 2004
    Posts:
    623
    Likes Received:
    0
    Location:
    houston/san antonio texas
    how much did everyone take out of the back?
    i took 17" from each side of mine then later on took 3" more per side. taillights sat right on top of the frame
    [​IMG]
    [​IMG]

  19. mudman2882

    mudman2882 1/2 ton status

    Joined:
    Aug 3, 2002
    Posts:
    144
    Likes Received:
    0
    Location:
    Lubbock, Tx
    I used the stock mount for the fenders and cut them to fit.

    [​IMG]

    [​IMG]

    [​IMG]

    As for the fender, I did skin it and angle it in. I wanted to not have the crease in it. I had to take out the blower motor/ac unit.

    [​IMG]

    blazd88 - I am probably going to Las Cruces but am not taking my Blazer. Only going to be riding. Although I may go to the Canadian that weekend.

  20. gmc4cw

    gmc4cw 1/2 ton status GMOTM Winner

    Joined:
    Jul 19, 2006
    Posts:
    3,907
    Likes Received:
    0
    Location:
    west chester, Pa
    thanks. :waytogo: those were exactly what I needed to see to proceed with mine. luckily I have an extra rad support to play with.
