Truggy concept...

Discussion in 'The Garage' started by MNorby, Jul 17, 2006.

  1. MNorby

    MNorby 3/4 ton status Premium Member GMOTM Winner

    Joined:
    Dec 10, 2001
    Posts:
    6,125
    Likes Received:
    53
    Location:
    Powell, Wy
    I've been beating this to deat about redo-ing my rear cage and ditching the 4 seater idea since the truck frame really doesn't co-operate well with the idea and kills all my storage room. Here is what I am thinking. More triangulation obviously but this would be the basic shape. Pros/Cons, constructive criticism.... Thanks

    Later in life I could link the rear and ditch the rest of the back too


  2. SCOOBYDANNN

    SCOOBYDANNN 1/2 ton status

    Joined:
    Sep 4, 2001
    Posts:
    2,129
    Likes Received:
    21
    Location:
    El Paso, TEXAS
    I think you can do the cage like what is above and still have the seat back there. Have it on an easy (pin on and off) latch system and when you don't need it take it out. I gonna do something like it on mine. I like the idea of being able to take a couple of people to the trail but as soon as it gets harry everyone is walking.

  3. MNorby

    MNorby 3/4 ton status Premium Member GMOTM Winner

    Joined:
    Dec 10, 2001
    Posts:
    6,125
    Likes Received:
    53
    Location:
    Powell, Wy
    I was thinking of making the back seat face backward but easily removeable. With it where it is sitting now I have no room for spare and tools, etc

  4. MNorby

    MNorby 3/4 ton status Premium Member GMOTM Winner

    Joined:
    Dec 10, 2001
    Posts:
    6,125
    Likes Received:
    53
    Location:
    Powell, Wy
    went ahead and cut off rear top cage and was playing with a pice I had bent for something else but it almost fits. It is going to turn into a 3 seater now.
    [​IMG]

  5. BranndonC

    BranndonC 3/4 ton status

    Joined:
    Mar 18, 2002
    Posts:
    8,591
    Likes Received:
    0
    Location:
    Anaheim, Ca
    replace the back seat with a fuel cell and chop off the frame behind the rear shackle
    edit
    looking closer, you'd have to link it to really be able to cut much off

  6. MNorby

    MNorby 3/4 ton status Premium Member GMOTM Winner

    Joined:
    Dec 10, 2001
    Posts:
    6,125
    Likes Received:
    53
    Location:
    Powell, Wy
    yeah, later in life or this winter I think I may link it and whack off frame in back and cut the cage shorter too to like where my back bars come in in this concept pic. Untill then I'll run 3 seater and full frame.

  7. MNorby

    MNorby 3/4 ton status Premium Member GMOTM Winner

    Joined:
    Dec 10, 2001
    Posts:
    6,125
    Likes Received:
    53
    Location:
    Powell, Wy
    well went ahead and changed it. I think it loks better and still has function




  8. stallion85

    stallion85 1/2 ton status

    Joined:
    Jul 11, 2003
    Posts:
    3,659
    Likes Received:
    0
    Location:
    Cedar City, UT
    I think a cross bar in the back wouldn't be a bad idea, but yes I too think looks better with the new design....

  9. MNorby

    MNorby 3/4 ton status Premium Member GMOTM Winner

    Joined:
    Dec 10, 2001
    Posts:
    6,125
    Likes Received:
    53
    Location:
    Powell, Wy
    yeah, here is kinda a quick sketch


  10. Drey

    Drey 3/4 ton status

    Joined:
    May 8, 2003
    Posts:
    8,288
    Likes Received:
    0
    Location:
    Iowa
    It used to be such a nice shortbox


    [​IMG]

  11. 85mudblazin

    85mudblazin 1/2 ton status

    Joined:
    Mar 26, 2004
    Posts:
    3,951
    Likes Received:
    0
    Location:
    Austin,TX
    Dude just keep your stupid comments to yourself.:rolleyes:

  12. Drey

    Drey 3/4 ton status

    Joined:
    May 8, 2003
    Posts:
    8,288
    Likes Received:
    0
    Location:
    Iowa
    Sorry Im a sheetmetal junkie, and I still remember when that thing was on 31s and had a 305

  13. MNorby

    MNorby 3/4 ton status Premium Member GMOTM Winner

    Joined:
    Dec 10, 2001
    Posts:
    6,125
    Likes Received:
    53
    Location:
    Powell, Wy
    i kinda miss the body but i drove it to the gas station tonight and it was all worth it for the openness. Can't wait to start wheelin
