Whoo Hooo Jimmy Crawler project almost done

Discussion in 'The Garage' started by 82dieselburb, Nov 17, 2005.

  1. 82dieselburb

    82dieselburb 1/2 ton status

    Joined:
    Jan 6, 2004
    Posts:
    105
    Likes Received:
    0
    Location:
    central Florida
    Well it's only about 8 months behind schedule but my jimmy is just about done.I've posted a few pics of the build a while back.

    One year ago it looked like this
    [​IMG]

    This was my first truck that I have built and it has been a learning experince.
    I got alot of ideas and tech from reading post on this board.
    After many many hours and lots of $$$$ its just about ready for the trails.

    [​IMG]

    [​IMG]

    [​IMG]

    Anti wrapbar

    [​IMG]

    [​IMG]


    I still need to: Finish running brake lines
    Mount up hydro assist ram and HD tierod
    Make exocage on the front
    Relocate dual batterys to bed so I can mount air filter for
    turbo on the firewall
    Install lights on the front
    Work all of the bugs out of it and a bunch of small stuff
    That I can't remember right now.
