1976 GMC Jimmy

C

Chip Cross

Registered Member
Joined
Apr 13, 2010
Posts
91
Reaction score
0
Location
Gonzales,La
For sale is my Jimmy with a GM 5.3 swap into the truck and I replaced everything from the fuel tank to the fuel rail on the motor with new parts. The fuel system is all plumbed in -06 Aeroquip socketless hose and -06 socketless fittings. I replaced the tank with a brand new tank and sending unit for a 1991 Jimmy and put the pump in the tank. I used a Holley/Walbro 255 LPH forced induction pump in the tank and a regulator/filter from a 99 to 03 Vette. I am the 4th owner of this truck and this truck is an original Arizona truck so there is very little rust on it at all. I have receipts for everything that has been done to this truck and it adds up to 27K. The only thing I don't have any receipts on is the axles which came from a 1986 CUCV with 28,XXX miles on it.








































I just replace the radiator with a new one from Jegs I put a fan shroud and a 16 inch HD 2200 CFM E fan.

Radiator and E fan



The power steering and trasmission coolers are plumbed in -06 socketless hose and -06 socketless fittings.

Power steering cooler

Transmission cooler

Fan switch

Specs :

GM 5.3 from a 2006 GMC Sierra with 38,XXX miles on it
Motor, harness and PCM came from Pacific Fabrication<-- These guys are GREAT!
Street and Performance LS motor swap plates.
Fleabay cold air intake.... basically a 4 inch 90 a 4 to 3 1/2 reducer for the mass air flow sensor and a K&N clamp on with a outerwear. It is nothing fancy but it is good as a wet dream!
Hughes performance flex plate and Tq converter spacer.
Motor has mid length ceramic coated headers from Street and Performance
for a 5.3 swap into a 1973 to 87 GM Truck. I used a single Dynomax x flow muffler and no cats. The truck sounds great!
New Taylor 10.4 wires, Taylor plug boots and with Bosch Platinum plugs
Flushed out the engine when we swapped it in. All I have ever ran in the motor is 5W20 Royal Purple oil.
Truckshop Performance tune that really woke up this motor!
Two new Diehard batteries with a 100 month warranty that breaks down like this 36 month free replacement and 64 month pro rated replacement.
New hydoboost brake system complete from the brake booster to the rearend it stops great and drives like a Caddy!
The inside of the tub has been Line X'ed
3000 watt continuous 6000 watt max inverter
New 31 gallon fuel tank with skid and very nice rear offroad bumper

Dana 60 front
Lock Right
1/4 Diff Cover
4:56 gears
New rotors, calipers and studs
New Wheel bearings
King Pins reworked
2.5 inch BDS front springs
ORD HD grease able shackles
ORD sway bar dico
ORD Steering box brace

14 Bolt rear
Detroit locker
4:56 gears
1/4 Diff cover
U joint / yoke rock guard
Rear disc conversion
New bearings and seals
shock mounts moved
axle perches moved
4 inch BDS rear springs
ORD HD grease able shackles

Built TH400 just changed the fluid
6 bolt round adapter
6 bolt round NP 205
New bearings, gaskets and seals in the NP 205
Twin sticked with JKW shift rails and NWF cable shifter

New 17X9 Pro Comp 1069 wheels with new 36X13.50X17 Irok bias tires. The tires have 78 miles on them and measure out the same as a 37x14.00X17 Irok which is 36.8 inches. I also have a 5th matching tire but no rim for it they are on a national back order

I would drive this thing anywhere in the U.S. Since the motor swap I have put about 500 miles on the truck and it runs flawlessly!

I am asking $10,000.00 and price is firm.

I need this thing gone yesterday, I am fighting Kidney cancer and I am going to lose my job and insurance soon. I need to put some coin in the bank.

I would look at a trade + cash my way.

Last edited:
Wow man crazy! Im shocked! You were so excited about it when you got it. I dont see why you dont just drive it.

On second thought, that may be what you end up doing at your price. Its VERY appropriately priced and VERY worth it!!! Trouble is, generally the people that have that kind of coin arent quite looking for that truck. They want something pretty or something that looks like a buggy.

Like i said though, thats a way fair price! You could not build that truck for 15k. So, If someone comes along, who has the money, and knows that, you will be set!

y5mgisi said:
Wow man crazy! Im shocked! You were so excited about it when you got it. I dont see why you dont just drive it.
Click to expand...
I love it but... I am always looking for something cooler. It drives like a Caddy and it rides pretty for a leaf sprung rig. The EFI 5.3 is just freakin sweet hands down out of the 8 1973 to 1987 Chevy or GMC trucks I have own this one it the best.

y5mgisi said:
On second thought, that may be what you end up doing at your price. Its VERY appropriately priced and VERY worth it!!! Trouble is, generally the people that have that kind of coin arent quite looking for that truck. They want something pretty or something that looks like a buggy.

Like i said though, thats a way fair price! You could not build that truck for 15k. So, If someone comes along, who has the money, and knows that, you will be set!
Click to expand...
I agree 110% I love this truck but if someone has the coin I will give them the title.

scottsdale86 said:
Awesome rig!! I so would own this if i had the coin. I need to get rid of my 68 chevelle first. Too many toys. :)
Click to expand...
68 Chevelle ? :woot::haha::bow:

I love this truck but if someone has the coin I will give them the title
Click to expand...

Been there and its happened! Kinda makes it worth it when you get the money out of it that you want.

Yup 68' factory 307 auto car with a big block and dual 750's under the stock hood with a th400 and 12bolt rear end. Just needs steeper gears and a high torque starter. Will be my summer project to finish it and then part with it. I have had it 16 years since i was 17 and had some good times with that car. I can say that on more than one occassion CHP's in their 5.0's they used to drive back in the day could not touch this car on the freeway. Pulled away from one who looked at me while i was getting on the freeway and i KNEW he wanted to stop me. I got on it doing about 60 and in about 3 seconds was way over 100. After a ways i got off the 15 fwy at the mcdonalds and pulled in for a soda and a few min later he came rolling up. LOL He just wanted to check it out and what was under the hood. LOL He was a car guy. I lucked out on that one. When i popped the hood he was like oh shiz! No wonder you left me. I bought him a coke and we BS'ed for awhile. Shook hands and he left. Good old times.

Wish I could spend that much money but I think the wife would kill me in my sleep.... Good luck with the sale!

Ttt with new pictures not really trying to push the sale of the truck but I found a 64 Chevy I must have!
