anybody know where i can find a explosion diagram of a 1990 7.3 ford stanadyne pomp?
CK5
Register an account today to become a member! Once signed in, you'll be able to participate on this site by adding your own topics and posts, as well as connect with other members.
7.3 ford
- Thread starter brian wafer
- Start date
had one apart ,too replace trottle shaft o rings. the are not the same as a 6.2,it has 2 extra springs one i,m sure where it goes but the second one i,m not 100% sure.didn,t notice them and they make it harder to take apart,the small one kind off fell out of nowhere. put pomp back together and it doesn,t start. i don,t see them in your diagram,looks more like a 6.2. thanks
took the pomp out yesterday and will send to repair shop!
The GM diagram was the only one I could find online... I'm sure there are repair manuals out there somewhere for the Ford. Do you have access to ALLDATA?
