Headlight bezel dimensions

[4x4_76]

I need couple dimensions from single headlight bezel; one from hood edge to the center of headlight, and other from most inner edge of fender to the center of headlight.

I don't have bezels yet, but need to make brackets for H3/H7 headlights, to tilting front clip



[tRustyK5]

What year? 73-79? '80? 81-89?

I have an '87 with single headlights here if that works.

Rene



[4x4_76]

Oh yeah, I forgot the year It's my -82 Suburban



[tRustyK5]

4.75" to center of light (121 mm)

4.625" down to center of light from hood edge. (118 mm)

3.75" down measured from underside of trim. (95 mm)

Hope that helps.

Rene



[4x4_76]

Great, thanks! That really helps



[tRustyK5]

Anytime...

rene
