New Shop to the Forum

T

TwiztedEngineering

1/2 ton status
Joined
Feb 9, 2008
Posts
117
Reaction score
0
Location
Broomfield, CO
Hi All! I'd like to introduce my shop to these forums. We are Twizted Engineering, and are located in Broomfield, CO. We customize most anything, with a focus on off-road vehicles - especially Chevy/GM vehicles since those are what I grew up with! We will be continuing to add more and more content to our website (www.TwiztedEngineering.com) in the near future, and currently offer products such as linked suspension bracketry, shackle flips (including a new design for 88-98 GM's, and versions with Joints in the shackles), fabricated differential covers, steering parts, complete disc brake conversions, etc... If you don't see something on the website, please call us at (303) 225-0507 because we might already have it or at least be working on it!!

Welcome!

Nice site and looks like alot of nice products i like the complete 14 bolt disk swap sure would make it easy.. And that truss is sick

Ten_Bucks said:
Welcome to CK5! Are there any more pics of the rig pictured in your sig? What are the specs on it? Thanks in advance.

Scott
Click to expand...
Scott,
The specs are as follows...
Front Suspension: 3-Link with a Track bar, Custom Transmission Crossmember/Link Mount, Crossover Steering with Hydro Assist, 16" Travel 2.5" Dia Fox Coilovers
Rear Suspension: 3-Link with a Track bar, Angled Upper Link to combat Engine Torque, Ford Torsion Bar converted to a super soft Rear Anti-Sway bar, 14" Travel 2.5" Dia Fox Coilovers mounted at an angle to achieve as much wheel travel as the front (if not a little more!)
Drivetrain: 454ci Big Block Swap; Built 4L60E transmission; NP241C Transfer Case; Ford High Pinion D44HD Front Axle with HD Shafts, Super Joints, 4.88 gears, ARB Locker; GM 14 Bolt Full Float Rear Axle with stock shafts, 4.88 gears and an ARB Locker
Exterior: A Fair bit of Body Damage, and getting more and more each trip; T-Max 10,000lb Winch on a custom front winch plate
Interior: Flamed Guages, Stereo System, and yes, even the A/C still works! ...Wheelin' in Style!

I'll try to get some pics posted up soon for ya!

Darren

Pics of Twizted's Shop Truck...

Ok guys, here are a few teaser shots for you. There are more pics at http://s297.photobucket.com/albums/mm223/TwiztedEng/Truckie/ if you are interested.






-Darren

TwiztedEngineering said:
Scott,
The specs are as follows...
Front Suspension: 3-Link with a Track bar, Custom Transmission Crossmember/Link Mount, Crossover Steering with Hydro Assist, 16" Travel 2.5" Dia Fox Coilovers
Rear Suspension: 3-Link with a Track bar, Angled Upper Link to combat Engine Torque, Ford Torsion Bar converted to a super soft Rear Anti-Sway bar, 14" Travel 2.5" Dia Fox Coilovers mounted at an angle to achieve as much wheel travel as the front (if not a little more!)
Drivetrain: 454ci Big Block Swap; Built 4L60E transmission; NP241C Transfer Case; Ford High Pinion D44HD Front Axle with HD Shafts, Super Joints, 4.88 gears, ARB Locker; GM 14 Bolt Full Float Rear Axle with stock shafts, 4.88 gears and an ARB Locker
Exterior: A Fair bit of Body Damage, and getting more and more each trip; T-Max 10,000lb Winch on a custom front winch plate
Interior: Flamed Guages, Stereo System, and yes, even the A/C still works! ...Wheelin' in Style!

I'll try to get some pics posted up soon for ya!

Darren
Click to expand...

TwiztedEngineering said:
Ok guys, here are a few teaser shots for you. There are more pics at http://s297.photobucket.com/albums/mm223/TwiztedEng/Truckie/ if you are interested.






-Darren
Click to expand...

Very nice setup and thanks for posting the pics.

Scott

Do you have a price or can you put a kit together for the rear disk swap for a 14 bolt, i dont think any one makes one with the hard lines tabs clips and steel braided lines.I dont need the rotors or calipers. And a price would be nice i am in need of 2 complete sets.
are you going to change the design of the brackets so a spacer is not needed it seeems alot of the co are going to this design?

Disc Brake Kit - Mod

mnstrburbon said:
Do you have a price or can you put a kit together for the rear disk swap for a 14 bolt, i dont think any one makes one with the hard lines tabs clips and steel braided lines.I dont need the rotors or calipers. And a price would be nice i am in need of 2 complete sets.
are you going to change the design of the brackets so a spacer is not needed it seeems alot of the co are going to this design?
Click to expand...
Mnstrburbon,
I'm actually glad you asked me about the spacers vs the bent plate. I persoanlly don't like the design of the formed plate because it is very difficult to form a plate of steel with two bends and keep the surfaces exactly parallel. If they are not parallel, you will find that your brake pads will wear unevenly and quicker than normal. I know that if you can keep your quality control super-tight, there is really no reason not to do it that way, but I don't trust putting that into someone else's hands (and I don't have a way to form them in-house). So a very simple solution to that is to just keep the spacers! If you go to my website (www.TwiztedEngineering.com) and look at my kit, you'll see that I don't use little cut pieces of tube for spacers like most shops do - I use a full round spacer that has the bolt holes cut into it - this is a much stronger setup than the other spacer designs. Also, I suggest tacking the brackets to the spacers with a welder once you position your calipers where you want them (my main brackets have many options for caliper rotation). This way, you have a 100% bulletproof setup, with no chance for mis-aligned calipers!

As far as a complete kit, yes I do sell that, and I have that on the web for $385 - but that includes everything - even the calipers and rotors. I have another "kit" that's not listed on the website yet which is exactly what you asked for. I put it together for another customer that didn't want to pay for shipping of the rotors and calipers. It is basically a complete kit minus the 2 rotors, the 2 calipers, and the 2 hard lines. It sells for $240, and includes all the bolts, brackets, SS brakelines, tabs, clips, and adapter fittings you need. PM me if you'd like to go any further with that!
Thanks for the interest!!

-Darren
