BehemothDT
TORQUE MONSTER
Here is our new figure 8 to 6 bolt round clocking adapter kit.
Laser cut and precision machined steel.
It is only 5/16" (0.313") thick, which maximizes shaft spline engagement.
It uses flat head socket cap screws so there is never any fear of threads pulling out, like with other similar kits that use studs. They can be ordered spot welded into place or loose.
Once the plate is bolted to the face of your NP205, you then install the aluminum seal retainer.
All pieces fit snug together with spigot/bore for proper alignment (not positioned by bolt pattern like some kits.)
Please specify large bearing (90mm, 3.543") or small bearing (80mm, 3.150") when ordering. We also sell a conversion bearing kit to put a big bearing shaft in a small bearing case without the need for machine work.
$120 shipped in USA.
To place an order, send us a PM, email, or call/text. We will send an itemized invoice to your email which you can pay with credit card, or PayPal.
Laser cut and precision machined steel.
It is only 5/16" (0.313") thick, which maximizes shaft spline engagement.
It uses flat head socket cap screws so there is never any fear of threads pulling out, like with other similar kits that use studs. They can be ordered spot welded into place or loose.
Once the plate is bolted to the face of your NP205, you then install the aluminum seal retainer.
All pieces fit snug together with spigot/bore for proper alignment (not positioned by bolt pattern like some kits.)
Please specify large bearing (90mm, 3.543") or small bearing (80mm, 3.150") when ordering. We also sell a conversion bearing kit to put a big bearing shaft in a small bearing case without the need for machine work.
$120 shipped in USA.
To place an order, send us a PM, email, or call/text. We will send an itemized invoice to your email which you can pay with credit card, or PayPal.
