Oil Pump bolt torque spec? 65ft?

[K85 Octane]

THIS IS HOW YOU TITLE A SPECIFIC QUESTION DAMMIT. When someone tries to search for an answer, you type your best guess into the search bar. I like to use "titles only", simply cause searching the entire post is retarded. So, needless to say I've searched for the answer already and only come back with 3 pages of "hi flow or standard pump" threads. GEZZZ

Did I read the torque on the oil pump mounting bolt correct? Does 65lb ft sound right?

Thanks



(ps) with a title like this, the next person SHOULD have no problem finding the answer IF THEY SEARCH! Pissy mode off



[djtejas]

My book says 65 ft lbs



[K85 Octane]

thank you
and
all those that will read this in the future thank you



[Deuling]

noted!!!



[4X4HIGH]

I have always torqued the oil pump bolt to 50 ft/lbs. I have never seen a spec in any book for it and I would be interested to know where someone seen it in a book.



[zombie1969]

50ft lb is what Ive always found and used.65 would be a head bolt spec or main cap bolt.



[djtejas]

I have always torqued the oil pump bolt to 50 ft/lbs. I have never seen a spec in any book for it and I would be interested to know where someone seen it in a book.

It's in Chilton...



[djtejas]

I have always torqued the oil pump bolt to 50 ft/lbs. I have never seen a spec in any book for it and I would be interested to know where someone seen it in a book.

Also from Jegs...

http://www.jegs.com/s/tech-articles...title=Small+Block+Chevy+Engine+Specifications

and Summit...

http://www.summitracing.com/expertadvice/storydetail/chartsandguides/Chevy-Torque-Specs/



[4X4HIGH]

It's in Chilton...

What Chiltons book do you have? I have every large Chiltons book that covers from 1964-2002 and none of them list oil pump bolt torque spec.



[djtejas]

I have the Chilton's for Full-Size GM Trucks 1980-87

Book # 28622

It's on page 3-52



[4X4HIGH]

I have the Chilton's for Full-Size GM Trucks 1980-87

Book # 28622

It's on page 3-52

My book cover 79-86 then another 86-90. Guess we have different volumes of the Chiltons book.



[zombie1969]

I got the Chilton 64-71 version and it doesn't specify the oil pump torque spec.I have seen 50lb several times from different sources and that's what I use and never had a pump fall off so Ill stick with it.Who's info is correct?

Part Bolt Size Minimum Torque: Maximum Torque: Camshaft sprocket 5/16"-18 15 ft. lbs. 25 ft. lbs. Connecting rod 3/8"-24 30 ft. lbs. 35 ft. lbs. *Cylinder head (oiled)7/16"-14 60 ft. lbs. 70 ft. lbs. Exhaust Manifold to Cylinder Head (Center) 3/8"-16 25 ft. lbs. 30 ft. lbs. Exhaust Manifold to Cylinder Head (Ends) 3/8"-16 15 ft. lbs. 20 ft. lbs. Fan Blade Assembly to Flange 5/16"-24 15 ft. lbs. 20 ft. lbs. Flywheel Housing to Crankcase 3/8"-1625 ft. lbs.30 ft. lbs. Flywheel Housing plate cover 1/4"-2010 ft. lbs.12 ft. lbs. Intake Manifold to Cylinder Head 3/8"-16 25 ft. lbs. 35 ft. lbs. Main Bearing Cap bolts (oiled) 7/16"-14 600 ft. lbs. 70 ft. lbs. Oil Pan Drain Plug Special 25 ft. lbs. 30 ft. lbs. Oil Pump Cover to Body 1/4"-20 6 ft. lbs. 9 ft. lbs. Oil Pump to Rear Bearing Cap Bolt 7/16"-1445 ft. lbs. 50 ft. lbs. Pulley to Balancer Hub 3/8"-24 15 ft. lbs. 20 ft. lbs. Carburetor Nuts 5/16"-24 12 ft. lbs. 15 ft. lbs. Water Pump Bolts 3/8"-16 30 ft. lbs. 20 ft. lbs. Thermostat Housing 3/8"-16 25 ft. lbs. 35 ft. lbs. Oil Filter bolt 1/2"-13 20 ft. lbs. 30 ft. lbs. Starter Bolts 3/8"-16 25 ft. lbs. 35 ft. lbs. Generator Bolts 3/8"-16 25 ft. lbs. 35 ft. lbs. Fuel Pump Bolts 3/8"-16 25 ft. lbs. 35 ft. lbs. Valve cover screws (inch lbs)1/4"-2020 in. lbs.25 in. lbs. Temperature switch 1/2"-pipe thread15 ft. lbs.20 ft. lbs. Spark plugs 14 mm25 ft. lbs.25 ft. lbs.



[cybrfire]

I got the Chilton 64-71 version and it doesn't specify the oil pump torque spec.I have seen 50lb several times from different sources and that's what I use and never had a pump fall off so Ill stick with it.Who's info is correct?

Part Bolt Size Minimum Torque: Maximum Torque: Camshaft sprocket 5/16"-18 15 ft. lbs. 25 ft. lbs. Connecting rod 3/8"-24 30 ft. lbs. 35 ft. lbs. *Cylinder head (oiled)7/16"-14 60 ft. lbs. 70 ft. lbs. Exhaust Manifold to Cylinder Head (Center) 3/8"-16 25 ft. lbs. 30 ft. lbs. Exhaust Manifold to Cylinder Head (Ends) 3/8"-16 15 ft. lbs. 20 ft. lbs. Fan Blade Assembly to Flange 5/16"-24 15 ft. lbs. 20 ft. lbs. Flywheel Housing to Crankcase 3/8"-1625 ft. lbs.30 ft. lbs. Flywheel Housing plate cover 1/4"-2010 ft. lbs.12 ft. lbs. Intake Manifold to Cylinder Head 3/8"-16 25 ft. lbs. 35 ft. lbs. Main Bearing Cap bolts (oiled) 7/16"-14 600 ft. lbs. 70 ft. lbs. Oil Pan Drain Plug Special 25 ft. lbs. 30 ft. lbs. Oil Pump Cover to Body 1/4"-20 6 ft. lbs. 9 ft. lbs. Oil Pump to Rear Bearing Cap Bolt 7/16"-1445 ft. lbs. 50 ft. lbs. Pulley to Balancer Hub 3/8"-24 15 ft. lbs. 20 ft. lbs. Carburetor Nuts 5/16"-24 12 ft. lbs. 15 ft. lbs. Water Pump Bolts 3/8"-16 30 ft. lbs. 20 ft. lbs. Thermostat Housing 3/8"-16 25 ft. lbs. 35 ft. lbs. Oil Filter bolt 1/2"-13 20 ft. lbs. 30 ft. lbs. Starter Bolts 3/8"-16 25 ft. lbs. 35 ft. lbs. Generator Bolts 3/8"-16 25 ft. lbs. 35 ft. lbs. Fuel Pump Bolts 3/8"-16 25 ft. lbs. 35 ft. lbs. Valve cover screws (inch lbs)1/4"-2020 in. lbs.25 in. lbs. Temperature switch 1/2"-pipe thread15 ft. lbs.20 ft. lbs. Spark plugs 14 mm25 ft. lbs.25 ft. lbs.

I'm bettin' that's a typo.



[K85 Octane]

I have the Chevrolet Shop Manual #ST-330-85, PAGE 6A2-39. It's brown and has Chevy logos all over it. Mine calls for 65lbs.

PS> The pump I pulled out was a M55HV. The pump I put in is a 10553, but the body is still stamped M55. However, the 10533 is the thicker body and bolt area. Strange though, both looked damn close in size, even though one was a HV pump. Dunno
