PICS 4 WHERE all the 350 TBI Engine Brackets go

[4x4chvy]

Someone please put this where it can be Easily Found in the Future.
I just went thru a nightmare trying to figure this mess out becasue my buddies kid threw away the "dirty" piece of paper that I had drawn all the bracket locations and positions on for an engine swap.

1987 K5, 350 TBI 4WD with A/C Engine Bracket Location Pics -



[BoondocK5]

I'm not going to be much help. Sorry.

All i have is the two aluminum brackets that are used for the serpentine set up. Which is what I highly suggest to you. Time to visit Pick-n-pull.



[82355]

I guess I have just done enough of them, that I find them rather simple to put back together.

Martin
