Source for cucv info on everything about them.

uao85

1/2 ton status
Joined
Jan 2, 2004
Posts
1,867
Reaction score
1
Location
Edge of insanity
Hey guys I just found a link to find out anything you ever wanted to know about the cucv series military chevy vehicles.

https://www.logsa.army.mil/etms/ind...f917c753c-F9971659-97EE-A149-6F2D2497E8387BFF

On that page, under "Pub Title", type in whatever series the truck is, ex. m1008 or m1010, etc etc..........Also whenever it comes up with a list of publications, there are restricted, and public documents. Most are public documents, but there are some that are private and you need an access password to access them. To find out if they are accessable or not, just place the cursor over the link and it will show the html link in the bottom left of the internet window. If it says "data A" near the begining, then you can access it, but if it says "data C" then its a private document. I havent tried to access the date b or d documents though. Sorry if this happens to be a repost. I talked on the phone today for a half hour trying to find this page and get access to it, so I thought I would pass it along.

Remington

mmmm the other half to my post. would of been nice to added it there.


Metrodps said:
OK so I was bored today and did this to see how colors would look on truck

Just use paint brush and fill in to get a look at diff colors.

NOW the true find:
All the info you could ask for about CUCV trucks or regular ones. These PDF docs have great info and pics and cover M1008, M1008 A, M1009, M1010, M1028, M1028 A and M1031 . Just google the number (ie: TM then number) and you can down load them all for FREE some guy sells them for $9.95 + shipping or download on eBay. :haha:

TM 9-2320-289-20 unit maintance manual 940 pages
TM LO 9-2320-289-12 Lubrication order 12 pages: capacities/ types/ when change
TM 9-2320-289-10 Operators manual 185 pages
TM 9-2320-289-20 Rear shaft remove / install (all except M1009) 29 pages
TM 9-2320-289-20P Maintance repair parts and tools list 724 pages
TM 9-2320-289-34 Maintance manual 1024 pages
TM 9-2320-289-34P Repair parts and special tools 1038 pages

They have good diagrams ie:

Argh photo bucket resized but you get the idea.

OK found this tid bit of info today too.

Sound levels stock CUCVs in cab
M1008, M1009, M1010, M1028, below 55 mph less than 85 dB; at 55 mph 85 to 91 dB

The things I find while looking up stuff for others.. :thinking:
