Suburban pics wanted with specific info

pma4x4

AKA Yankeeroad
Joined
Sep 10, 2012
Posts
1,037
Reaction score
130
Location
Apache Junction, Arizona
I have looked through the two sticky threads on "show your burb" but not many have specs.

I am looking for the 72-91 Suburban body with a 2.5" or 4" lift with either 33s or 35s.

I dont expect many replies but if you do have pics can you please post your lift and tire size.

Thanks

A little different.

91 3/4 ton with 1" Zero rate add a leaf's front/rear.

33x12.50x16.5's on 16.5x9.75" wheels





Keep in mind, these are well worn.

I'll see if i can find a pic with the new shoes.

88 1/2 ton

3" alcan custom springs all 4 corners
factory 10b's
33x12.5x15 mickeys
15x10 w/3.75 bs summit nomads
homemade swaybar disconnects (never disconnected)





86 3/4 ton, 350 SB, edelbrock 122 e-force supercharger, devils own progressive methanol/water injection, gear vendors overdrive, TH400, 14b full floating rear end, 4.11 gears, 4 inch lift provided by Super lift. new springs all round, ORD steering box brace, ORD anti-sway bar offset shackle set-up, 33 inch Maxis Monster Mudders, tactical armor front winch bumper. Waiting on an ORU roof rack that I ordered a YEAR ago!!! I think 4 wheel parts just bought them out so I might actually see it. Thinking about painting it a Nissan Path finder green called Whacky kacky.

2012-08-22 14.19.07.jpg

2012-10-17 13.18.07.jpg

2012-10-17 13.18.19.jpg

2012-10-17 13.18.31.jpg

No one else has anything? I know there are a ton of pics but most of the time people don't post the specs with them.


I'd go through the burb forum on here. There are a number of build threads with these specs.

I guess a few more mundane specs on mine are

stock 350tbi with throttle body spacer and aftermarket coil
stock 700r4
3.73 gears
15 mpg if kept on 55mph roads. goes down fast after that and wont stay in TC lockup. Needs 4.11's or 4.56's

All I am looking for is pics of 2.5" to 4" lifts with 33s to 35s for tires. I dont need any other specs.:whistle:

Just looking for the look of the stance and wheel clearance.

Last edited:
All I am looking for is pics of 2.5" to 4" lifts with 33s to 35s for tires. I dont need any other specs.:whistle:

Just looking for the look of the stance and wheel clearance.


Elyon just did...

4" superlift all around with 33's... :dunno:

These are all 4" with 35s or 315s. Pmed from LIVEAnimals I thought I would post them up anyways to help with a good database of mild 4" or smaller lifts.




















Just 2 inch lift front springs and 2 inch blocks in the back along with a pair of zero rates to help it match the front.

What brand?

Different brands sit different. Rough country lifts always seem a lot bigger than the same size tuff country

You probably already know the specs on mine but here goes….

- 4” front springs with ORD HD shackles. Unsure of spring brand as they were on my K10 when I bought it back in 1996

- ORD 4” rear shackle flip

- Bald Kumho 315/75R16 tires borrow from the K10 for a while








Same lift but with Superswamper Q78x16 tires. Same set up as Fred's cheap burb build in Peterson's 4Wheel & Off-Road
