WTB '85 and later pedals for hydro clutch and hydro brakes

[modernbeat]

Looking for a pedal set for a hydraulic clutch master AND hydroboost brakes. Need them shipped to Dallas, Texas.

Not sure what you've got? The easiest way to check is if there are two studs pressed into the pedal bracket that go through the firewall.

Looking for the pedals on the left (Hydro/Hydro). The pedals on the right are vacuum/mechanical.



[sweetk30]

fyi dont pass up vac brakes . some had the extra pin hole in the arm bracket for the hydro pin position.

i had a set like that once and cut the pin out of my auto pedel and welded it in the hydro clutch vac brake second hole and bam i had a setup that could do both style brakes.



[GonicGM]

Your bracket illustration is somewhat incorrect. Both hydro and vacuum brakes use studs through firewall. Two for hydroboost, four for vacuum.



[imiceman44]

Looking for a pedal set for a hydraulic clutch master AND hydroboost brakes. Need them shipped to Dallas, Texas.

Not sure what you've got? The easiest way to check is if there are two studs pressed into the pedal bracket that go through the firewall.

Looking for the pedals on the left (Hydro/Hydro). The pedals on the right are vacuum/mechanical.

I have the pedals you need out of a crew cab.
Pm on the way.
