Post your 6.2/6.5!
- Thread starter thirdstreettito
- Start date
MaxPF
1/2 ton status
Here's Great White:
1991 K5 (technically it was called a V10 Blazer by then, but I still call it a K5)
6.2 J-code - According to the air cleaner tag it is an RPO LMM engine rated at 165HP - engine has about 60k original miles on it
4L60 trans (aka 700R4) built with the Good Stuff
NP241 t-case
10b front axle, 4.56's with an Eaton E-Locker
14bsf rear axle, 4.56's with an Eaton E-Locker
37" Dick Cepek FC-II's on 15" soft-8 steelies
Sometime after the above engine bay pics were taken I added a 2nd battery (which made a HUGE increase in cranking speed - she starts easy now) and changed out the leaky, plugged brass radiator for a new aluminum/plastic jobbie from a NBS Vortec 454 app (same height and width as the OBS diesel radiator!).
In a week or two she will go under the knife again. This time, the 6.2 and 4L60 are going buh-bye, and a 12V Cummins and SM465 will take it's place. Gears will change from 4.56's to 3.23's to give good highway gearing. The NP241 will be retained for now, but will eventually be replaced with a 203-205 (maybe even a Lo-Max 205) doubler setup for better trail gearing.
Axles may get swapped out in the future. If so, it will be to a 3.21 geared ARB locked 14bff in the rear and a 3.25 geared ARB locked 609 setup in the front.
Sometime after the Cummins swap she will go under the knife again, but this time for cosmetic surgery. I have all the sheetmetal needed to restore her original un-wrinkled Sheet Metal Gang status. She will still see the trails afterwards, but no hard core metal crunching stuff. Mainly expedition, camping, and hunting duties. I want it to be nice enough that I won't be embarrassed to pick up a date in it
1991 K5 (technically it was called a V10 Blazer by then, but I still call it a K5)
6.2 J-code - According to the air cleaner tag it is an RPO LMM engine rated at 165HP - engine has about 60k original miles on it
4L60 trans (aka 700R4) built with the Good Stuff
NP241 t-case
10b front axle, 4.56's with an Eaton E-Locker
14bsf rear axle, 4.56's with an Eaton E-Locker
37" Dick Cepek FC-II's on 15" soft-8 steelies
Sometime after the above engine bay pics were taken I added a 2nd battery (which made a HUGE increase in cranking speed - she starts easy now) and changed out the leaky, plugged brass radiator for a new aluminum/plastic jobbie from a NBS Vortec 454 app (same height and width as the OBS diesel radiator!).
In a week or two she will go under the knife again. This time, the 6.2 and 4L60 are going buh-bye, and a 12V Cummins and SM465 will take it's place. Gears will change from 4.56's to 3.23's to give good highway gearing. The NP241 will be retained for now, but will eventually be replaced with a 203-205 (maybe even a Lo-Max 205) doubler setup for better trail gearing.
Axles may get swapped out in the future. If so, it will be to a 3.21 geared ARB locked 14bff in the rear and a 3.25 geared ARB locked 609 setup in the front.
Sometime after the Cummins swap she will go under the knife again, but this time for cosmetic surgery. I have all the sheetmetal needed to restore her original un-wrinkled Sheet Metal Gang status. She will still see the trails afterwards, but no hard core metal crunching stuff. Mainly expedition, camping, and hunting duties. I want it to be nice enough that I won't be embarrassed to pick up a date in it
Here is a picture of my rig! She is still under construction, but here are the current specs:
- 1985 GMC K5 Jimmy Sierra Classic with a 90 base model W/T front clip
- 6.2L Diesel turbocharged with a GM-3 off a 93 6.5L. Running a 3" straight pipe outside the frame, and currently working on an S10 airbox
- NV4500 / NP241 with electric speedometer out of a 90 Suburban. ESS vac pump for a tach down the road
- 4.56 gears with an open D60 front axle (needs SRW conversion) and ARB locked 14 BSF out back
- Shackle flip out back using 3/4 ton front hangers in the rear. Needs longer shackles, and zero rates to re-center the rear axle
- 4" lift springs up front.
- Needs longer shocks front and rear (going to go long travel to accommodate 56s up front eventually)
- Procomp extended SS braided brake lines
- Cobra CB radio installed on the center console
- Currently rolling on 285/75R16s, but I have just put a deposit on a set of 34x10.5x16" Interco LTBs
The truck looks really rough, with a rusty / beat up front clip & doors, but the tub is very solid. I plan to seal and paint the tub & good sheet metal I have stashed away next spring.
This truck is going to be used primarily for wheeling and hunting in the fall.
- 1985 GMC K5 Jimmy Sierra Classic with a 90 base model W/T front clip
- 6.2L Diesel turbocharged with a GM-3 off a 93 6.5L. Running a 3" straight pipe outside the frame, and currently working on an S10 airbox
- NV4500 / NP241 with electric speedometer out of a 90 Suburban. ESS vac pump for a tach down the road
- 4.56 gears with an open D60 front axle (needs SRW conversion) and ARB locked 14 BSF out back
- Shackle flip out back using 3/4 ton front hangers in the rear. Needs longer shackles, and zero rates to re-center the rear axle
- 4" lift springs up front.
- Needs longer shocks front and rear (going to go long travel to accommodate 56s up front eventually)
- Procomp extended SS braided brake lines
- Cobra CB radio installed on the center console
- Currently rolling on 285/75R16s, but I have just put a deposit on a set of 34x10.5x16" Interco LTBs
The truck looks really rough, with a rusty / beat up front clip & doors, but the tub is very solid. I plan to seal and paint the tub & good sheet metal I have stashed away next spring.
This truck is going to be used primarily for wheeling and hunting in the fall.
Here's my ride.
'90 K5 that I bought all stock in '94 with 49k on the ticker.
original 6.2 w/ single plane J-code, pump turned up about 1/6, dual exhaust with Flowmaster 40's
original and untouched 700r4 w/ big cooler
original and untouched 241 (leaks bad, is getting rebuilt soon)
1350 slip yoke rear driveshaft, stock front shaft
14FF rear, 4.10's, welded diff
D60 front, 35-spline chromo stubs, flanges, new non-neck Spicer inners and joints, Lock-right, 4.10
4" TC HD front springs
Sky shackle flip in back on stock springs
39.5" TSL's, 15x8 rims w/ 2.75" BS (redneck beadlocks)
garage built front and rear bumpers, rear has gas tank protection
Ramsey 9k winch
S&W rollcage kit
Corbeau front seat, single center mounted rear seat with harness for my son
This summer was new front fenders, new rear bed sides that are dovetailed about 6" per side (hence the currently straight sheetmetal), 1" tubing welded along body seam.
Rockers removed and replaced with 3x3 tubing, and additional 1.5" tubing kick outs and lower B-pillar protection, rockers are raised about 6" (doors have about 4-5" cut off the bottom of them to fit)
CS144 alternator swap
Line locks front and rear
interior light on manual switch
spare tire mount,
blah, blah, blah
'90 K5 that I bought all stock in '94 with 49k on the ticker.
original 6.2 w/ single plane J-code, pump turned up about 1/6, dual exhaust with Flowmaster 40's
original and untouched 700r4 w/ big cooler
original and untouched 241 (leaks bad, is getting rebuilt soon)
1350 slip yoke rear driveshaft, stock front shaft
14FF rear, 4.10's, welded diff
D60 front, 35-spline chromo stubs, flanges, new non-neck Spicer inners and joints, Lock-right, 4.10
4" TC HD front springs
Sky shackle flip in back on stock springs
39.5" TSL's, 15x8 rims w/ 2.75" BS (redneck beadlocks)
garage built front and rear bumpers, rear has gas tank protection
Ramsey 9k winch
S&W rollcage kit
Corbeau front seat, single center mounted rear seat with harness for my son
This summer was new front fenders, new rear bed sides that are dovetailed about 6" per side (hence the currently straight sheetmetal), 1" tubing welded along body seam.
Rockers removed and replaced with 3x3 tubing, and additional 1.5" tubing kick outs and lower B-pillar protection, rockers are raised about 6" (doors have about 4-5" cut off the bottom of them to fit)
CS144 alternator swap
Line locks front and rear
interior light on manual switch
spare tire mount,
blah, blah, blah
pseudomike
1/2 ton status
My '97 6.5. First pic when I got it. Rebuilt motor, turbo, built new bumpers, and install fisher plow.
sixb
1/2 ton status
Here's mine
Last edited:
four_by_ken
1/2 ton status
Meen Green
Registered Member
Here is my M1009, 93 6.5 gm-3 turbo, NV-4500, 208, 10bolts, 3.08's, and gov bomb in rear. And My M1028 stock with humvee radials
Watch your drag link with the 37's. Mine ate up the forward grease boot on hard right turns.
Meen Green
Registered Member
Thanks for the warning, but i am too big a p&*^y to cut the fenders at stock height so i can't steer it at all right now with the 37's on it. I am piecing together a 4" lift, i am down to needing extended brake lines, a set of zero rates, and all 4 shocks
Even so, it'll rub the drag link, lift or not. The backspacing on those factory rims pulls the sidewall in towards the draglink.
Oh shocks - JCWhitney and get the Rough Country Nitro 9000's. Good stuff.
Oh shocks - JCWhitney and get the Rough Country Nitro 9000's. Good stuff.
Thunder
3/4 ton status
Here's my new 6.5
98 K1500 6.5 TD, 46000 miles. 4L80E, 14Bsf 3.73 12.50 x 33 x15 Mts. Just put in a powertrax no slip. Relocated new PMD High and dry behind the grille next to the headlight. 2.5 crossover, 3" downpipe.. Somehow the soot trap just fell off. amazing how poop like that happens. Cleaned out the upper intake. realised i had better let my die grinder have its way with it for a little better air flow. Fun truck. Lotta tire burnin power for a 1/2 ton.
Oh... it has a locking hard Snugtop bed cover too keep all my spare parts, and getting unstuck stuff ( prolly going to need it with IFS) safe.
98 K1500 6.5 TD, 46000 miles. 4L80E, 14Bsf 3.73 12.50 x 33 x15 Mts. Just put in a powertrax no slip. Relocated new PMD High and dry behind the grille next to the headlight. 2.5 crossover, 3" downpipe.. Somehow the soot trap just fell off. amazing how poop like that happens. Cleaned out the upper intake. realised i had better let my die grinder have its way with it for a little better air flow. Fun truck. Lotta tire burnin power for a 1/2 ton.
Oh... it has a locking hard Snugtop bed cover too keep all my spare parts, and getting unstuck stuff ( prolly going to need it with IFS) safe.
dieselponyexpress
1/2 ton status
I doubt he's using the humvee radials on the original M1028 16"wheels. That said my plans are to mount 37/12.5/16 Parnelli Jones on the factory 16/6.5 steel wheels. Wondering what will happen to the drag link . . .
Sorry for hijacking this thread.
Walter
sixb
1/2 ton status
1992 C3500HD with a 6.5TD that's soon to go im my CUCV truggy
Meen Green
Registered Member
You'll rub the drag link.
Yes, he is running the stock wheels.
AJM, Yes i am running stock type wheels they are 16.5's i bought from a buddy, and they are humvee radials. Thanks for the tip on shocks, and i will check the draglink when i get it all together and can steer it.
Blam!
84CUCV
3/4 ton status
here some of mine.. pretty much all cucvs
84CUCV
3/4 ton status
some more
