Ryoken's 89 Crew Cab Tubebed build... aka Mutt....

Overview Gallery Discussion
Chief Brody said:
Yeah....I think your going a little heavy on the yellow...a p*ss coat is all it takes...:D Just kiddin'....seems I heard that somewhere before :haha:

It just ain't right not to be usin' Ryoken Green though....but in a pinch...
Click to expand...


got 3 cans of green sitting on the shelf now... ;)

ryoken said:
got 3 cans of green sitting on the shelf now... ;)
Click to expand...

Awesome to see ya building from scratch again, Brother..:waytogo:

You now better than I, how cool it is to gander at it once it's done and tell your self, I built that. Being good or bad, it never existed before you made it. :pimp:

ryoken said:
got 3 cans of green sitting on the shelf now... ;)
Click to expand...

I have never used a more durable rattle can zinc primer
I used the green zinc on some sandblasted Lugnuts then some Rattle can white
I have hit them many times with an impact
the white flaked off easily but the green is still holding up
awesome stuff


yay for tube fab! :woot: ;)



one thing I learned today when I took that back off to store in the garage, it'll be the last time I can do it without the engine hoist prolly... :doah: :haha:


once the side tubes start going in, it'll be too unwieldy without the crane...

76zimmer said:
I have never used a more durable rattle can zinc primer
I used the green zinc on some sandblasted Lugnuts then some Rattle can white
I have hit them many times with an impact
the white flaked off easily but the green is still holding up
awesome stuff
Click to expand...



:haha: nice... :bow:

imagine how good the 2 part zinc washes are... :eek1:

I'm sure it does fine.... it's the guys using cr@ppy enamel or lacquer primer that need to step it up to some zinc, epoxy or urethane...

ryoken said:
I'm sure it does fine.... it's the guys using cr@ppy enamel or lacquer primer that need to step it up to some zinc, epoxy or urethane...
Click to expand...

I'm sure you've said it before but since I'm too lazy to search, where do you get it? :D

Oh, we use a similar catalyzed product for aluminum signs, never thought about using it on steel.

How does that primer compare to say the Rustoleum Etching stuff on the shelf at Lowes? Ive used etching primer for years, going to duplicolor (because everything they make is watered down crap) to the rustoleum. Ive always had good results but wonder how much better this stuff is.

Also does it dry fast or is it a walk away over night deal?

it blows away anything rusto makes as far as etching goes.... by far the best etching air-dried primer.. only thing better is a 2 part zinc wash.. well, that and a 2 part epoxy will generally etch as good as this...

but any "self etching" primer in a spray can is a modern day marketing ploy with little to back it up chemically... they call just about anything self etching these days...

developed for alum, but those same properties make it great on steel too...

I go into all this in detail in the zinc thread...

https://ck5.com/forums/threads/zinc-chromate-tech.262999/


Mod edit, more good stuff here
https://ck5.com/forums/threads/ryokens-guide-to-rust-treatment-and-bodywork-101.283048/

Last edited by a moderator:
oh, and it dries damn fast... couple coats, dry to touch in 15 minutes or less...

just a couple pics today..... yesterday I got all the mount holes drilled and bolted up the coffin... today I pulled it off for the next month or so to fab up the back end of it in the shop..

the 2 back angle pieces where quite time consuming... this mitering stuff is a slow process... but got them fitted up... the x-brace was temp to control the top tube width...








the back 2 "points" will be cut off and 1/2 rounded when I bring the side angle tubes from the toolboxes in to that node... so they match the roundness of the top tube of the tubegate..










the rest of the weekend was spent beginning to build the tube gate and beginning the hinges.. but you'll have to wait till next weekend for pics of that... the hinges are gonna take forever... :doah:

it'll look goofy with the tubegate more than likely, but I haven't ruled it out.. the final decision and subsequent cutting will be made when I bring the angle ones in from the side boxes...

here's a quick pic with me holding the tubegate up there of the issue... it wont be a huge rounding... just enough to carry that 2" radius around the edge to the outer angled tube....












you can also see the beginning of one of the hinges sitting on top of that tube.. basically a 1.75 turning inside a 2".... I'll cut a window in one spot of the 2" to correspond with 2 sides "flattened" on the 1.75.. like a pickup hinge for removal...
